Velopedia Bicycle Archive

2012 KHS TC-150L

Original specifications.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #2025584
Model year
2012
Category
Hybrid
Sizes
16"
Colors
Blue/Silver, Gloss Pearl White
In this record
18 specifications · 2 archived images
Campaign
Original buildAlloy 6061

Manufacturer catalog

Published sizes and colors

1 size · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

16"

Published colors

Blue/SilverGloss Pearl White

Frameset

Frame MaterialAlloy 6061
ForkSpinner Odesa AC 63mm

Drivetrain

ShiftersShimano Revo twist, 7spd
Front DerailleurShimano TX-51
Rear DerailleurShimano Altus
CranksetAlloy forged 28/38/48t
Bottom Bracketcartridge type
CassetteShimano MegaRange 7spd 14-34t
ChainKMC Z7
Pedalsplatform

Brakes

BrakesAlloy linear pull

Cockpit & Contact Points

Headset1 1/8 threaded
HandlebarAlloy 80mm rise
StemAlloy quill
SaddleKHS Wide Comfort
SeatpostPost Modern Solo suspension

Wheels & Tires

RimsWeinmann Alloy
Front TireKenda 26x1.95"

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes48/38/28T · 14–34T · 7-speed
Lowest0.82:1 Highest3.43:1 Total range416%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC Z7
Search Amazon Search eBay
Cassette · Original
Shimano MegaRange 7spd 14-34t
Search Amazon Search eBay
Front tire · Original
Kenda 26x1.95" Replacement search: 26x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
Search Amazon Search eBay
More parts (2)Fewer parts
Brake pads · Original
Alloy linear pull
Search Amazon Search eBay
Rear derailleur · Original
Shimano Altus
Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Kenda 26x1.95"
Drivetrain
7-speed
Bottom bracket / shell
cartridge type
Campaign
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: Alloy 6061 · Fork: Spinner Odesa AC 63mm

Drivetrain

Check drivetrain wear →

Archived: Shifters: Shimano Revo twist, 7spd · Front derailleur: Shimano TX-51 · Rear derailleur: Shimano Altus · Crankset: Alloy forged 28/38/48t · Bottom bracket: cartridge type · Cassette: Shimano MegaRange 7spd 14-34t · Chain: KMC Z7

Brakes

Inspect the brakes →

Archived: Brakes: Alloy linear pull

Wheels and tires

Check wheels and tires →

Archived: Rims: Weinmann Alloy · Front tire: Kenda 26x1.95"

Controls and contact points

Archived: Headset: 1 1/8 threaded · Handlebar: Alloy 80mm rise · Stem: Alloy quill · Seatpost: Post Modern Solo suspension · Saddle: KHS Wide Comfort · Pedals: platform
