Lowest1.13:1
Highest4.17:1
Total range368%
Velopedia Bicycle Archive
At a glance
Archive #2025323- Model year
- 2012
- Category
- Road
- Sizes
- 49cm, 52cm, 54cm, 56cm, 58cm, 61cm
- Colors
- Gloss Black
- In this record
- 18 specifications · 2 archived images
Model history 9 other years
Browse other years
Compare side by side
Identification clues
2012 archived details
- Published colors
- Gloss Black
- Frame
- Alloy 6061 Double Butted
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildAlloy 6061 Double Butted
Frameset
| Frame Material | Alloy 6061 Double Butted |
|---|---|
| Fork | Carbon w/alloy steerer |
Drivetrain
| Shifters | Shimano Tiagra 10spd |
|---|---|
| Front Derailleur | Shimano Tiagra |
| Rear Derailleur | Shimano 105 |
| Crankset | KHS forged 50/34t |
| Bottom Bracket | Outboard Bearing |
| Cassette | Shimano CS4600 10spd 12-30t |
| Chain | KMC DX10 |
| Pedals | Monoblock Resin w/toe clips |
Brakes
| Brakes | Tektro R312 |
|---|
Cockpit & Contact Points
| Headset | FSA IS-3E |
|---|---|
| Handlebar | Anatomic Alloy |
| Stem | Alloy 3D forged |
| Saddle | KHS Sport Road |
| Seatpost | Q2 Carbon |
Wheels & Tires
| Rims | Mavic CXP22N |
|---|---|
| Front Tire | Kenda Kriterium 700x25c |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Kenda Kriterium 700x25c
Retailer offers
Vittoria Zaffiro Pro V Clincher Tire Black, 700x25
700x25c
Replacement option
Kenda Kriterium on eBaySponsored links
Tektro R312
More parts (5)Fewer parts
Shimano Tiagra
Shimano 105
Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.
Shimano Tiagra 10spd
FSA IS-3E
Mavic CXP22N
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Kenda Kriterium 700x25c
- Drivetrain
- 10-speed
- Bottom bracket / shell
- Outboard Bearing
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: Alloy 6061 Double Butted · Fork: Carbon w/alloy steerer
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano Tiagra 10spd · Front derailleur: Shimano Tiagra · Rear derailleur: Shimano 105 · Crankset: KHS forged 50/34t · Bottom bracket: Outboard Bearing · Cassette: Shimano CS4600 10spd 12-30t · Chain: KMC DX10
Brakes
Inspect the brakes →Archived: Brakes: Tektro R312
Wheels and tires
Check wheels and tires →Archived: Rims: Mavic CXP22N · Front tire: Kenda Kriterium 700x25c
Controls and contact points
Archived: Headset: FSA IS-3E · Handlebar: Anatomic Alloy · Stem: Alloy 3D forged · Seatpost: Q2 Carbon · Saddle: KHS Sport Road · Pedals: Monoblock Resin w/toe clips
