Ratio2.06:1
Estimated speed At 90 RPM
Gear
Uses front tire 26×2; rear size isn’t listed.
Velopedia Bicycle Archive
At a glance
Archive #10822- Model year
- 2006
- Category
- Mountain
- Original MSRP
- $599.00
- Sizes
- S, M, L, XL
- Colors
- Flat dark red
- In this record
- 22 specifications · archived image · original MSRP
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2006 archived details
- Published colors
- Flat dark red
- Frame
- Reynolds 520 Double Butted Full Chromoly
- Original equipment
- N/A
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildReynolds 520 Double Butted Full Chromoly · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Reynolds 520 Double Butted Full Chromoly |
| Fork | Khs |
| Fork Material | Chromoly, unicrown crown |
Drivetrain
| Crankset | Truvativ FiveD 33T w/guard, 33 teeth |
|---|---|
| Bottom Bracket | TruVativ Power Spline |
| BB Shell Width | 68mm English |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z51, 1/2 x 3/32" |
| Pedals | VP-X93, multifunction |
Brakes
| Brakes | Tektro alloy linear pull brakes, Tektro MT 2.1 front/Tektro MT2.1 rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless WTB ST |
|---|---|
| Handlebar | Truvativ LE Riserbar Ø31.8, 25mm rise |
| Stem | Truvativ XR 3D Ø31.8, 5° |
| Saddle | WTB Pure V Comp |
| Seatpost | Kalloy SP-602 |
Wheels & Tires
| Hubs | Front: Alloy disc, Rear: KK single speed disc rear |
|---|---|
| Rims | Sun doublewall, CR-18, 32-hole |
| Spokes | Stainless steel, 14/15ga. (2.0/1.8mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 2.00" Kenda Karma Folding Kevlar |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
26 x 2.00" Kenda Karma Folding Kevlar
Kenda Karma Kevlar on eBaySponsored links
Tektro alloy linear pull brakes
Tektro MT 2.1 front/Tektro MT2.1 rear levers
More parts (3)Fewer parts
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.00" Kenda Karma Folding Kevlar
- Drivetrain
- 1-speed
- Bottom bracket / shell
- TruVativ Power Spline · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: KHS · Chromoly, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Crankset: Truvativ FiveD 33T w/guard, 33 teeth · Bottom bracket: TruVativ Power Spline · Rear cogs: 1-speed, 16 teeth · Chain: KMC Z51, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro alloy linear pull brakes, Tektro MT 2.1 front/Tektro MT2.1 rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Sun doublewall, CR-18, 32-hole · Hubs: Front: Alloy disc, Rear: KK single speed disc rear · Front tire: 26 x 2.00" Kenda Karma Folding Kevlar
Controls and contact points
Archived: Headset: 1 1/8" threadless WTB ST · Handlebar: Truvativ LE Riserbar Ø31.8, 25mm rise · Stem: Truvativ XR 3D Ø31.8, 5° · Seatpost: Kalloy SP-602 · Saddle: WTB Pure V Comp · Pedals: VP-X93, multifunction
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
