Velopedia Bicycle Archive

2003 KHS F18-2

Original specifications: Shimano Tourney · 6-speed · mechanical rear derailleur · 18" wheels · 30.8 lb published weight.

Share owner experience

No archive photo is available for this record.

At a glance

Archive #38921

Model year: 2003
Category: Folding
Original MSRP: $449.00
Sizes: 13"
Colors: Matte Blue
Weight: 30.8 lb
In this record: 23 specifications · original MSRP

Original buildHi-tensile steel · Folding mix · 18" wheels

Manufacturer catalog

Published sizes and colors

1 size · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

13"

Published colors

Matte Blue

Frameset

Frame Construction	TIG-welded
Frame Material	Hi-tensile steel
Fork Material	Aluminum, unicrown crown

Drivetrain

Component Group	Folding mix
Shifters	SEC Twistshift
Rear Derailleur	Shimano Tourney TY-22
Crankset	Aluminum
Rear Cogs	6-speed, 14 - 28 teeth
Chain	KMC Z50, 1/2 x 3/32"
Pedals	Folding

Brakes

Brakes	Aluminum linear-pull brakes, aluminum levers

Cockpit & Contact Points

Headset	1" threaded steel
Handlebar	Aluminum
Handlebar Extensions	Not included
Stem	Aluminum, folding
Saddle	KHS Padded
Seatpost	Aluminum

Wheels & Tires

Hubs	Aluminum, nutted
Rims	Aluminum, 36-hole
Spokes	Stainless steel, 14ga. (2.0mm) straight gauge
Spoke Nipples	Brass nipples
Front Tire	18 x 1.50" street
Wheel Size	18" wheels

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Chain · Original

KMC Z50

1/2 x 3/32"

Search Amazon Search eBay

Front tire · Original

18 x 1.50" street Replacement search: 18x1.5 bicycle tire Before ordering: Check rim type and tire clearance.

Search Amazon Search eBay

Brake pads · Original

Aluminum linear-pull brakes

aluminum levers

Search Amazon Search eBay

More parts (1)Fewer parts

Rear derailleur · Original

Shimano Tourney TY-22

Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 18 x 1.50" street
Drivetrain: 6-speed

Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: · Aluminum, unicrown crown

Check paint damage, vent holes and accessible internal surfaces for corrosion. Look for dents, bent tubes and cracking around welded or brazed joints.

Drivetrain

Check drivetrain wear →

Archived: Group: Folding mix · Shifters: SEC Twistshift · Rear derailleur: Shimano Tourney TY-22 · Crankset: Aluminum · Rear cogs: 6-speed, 14 - 28 teeth · Chain: KMC Z50, 1/2 x 3/32"

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Aluminum linear-pull brakes, aluminum levers

Inspect pads, cables and housings, then examine both rim braking surfaces for concavity, cracking or heavy wear. Confirm each caliper returns and centers correctly.

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 18" wheels · Rims: Aluminum, 36-hole · Hubs: Aluminum, nutted · Front tire: 18 x 1.50" street

Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Controls and contact points

Archived: Headset: 1" threaded steel · Handlebar: Aluminum · Stem: Aluminum, folding · Seatpost: Aluminum · Saddle: KHS Padded · Pedals: Folding

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
