2000 KHS Pro ST

Original specifications: Shimano Deore LX · 9-speed · mechanical rear derailleur.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #45051
Model year
2000
Category
Mountain
Original MSRP
$1,199.00
Sizes
S, M, L
Colors
Black
In this record
24 specifications · archived image · original MSRP
Model history 1 other year

Browse other years

Compare side by side

Identification clues

2000 archived details

Published colors
Black
Frame
True Temper OX2
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildTrue Temper OX2 · Mountain Mix

Manufacturer catalog

Published sizes and colors

3 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

SML

Published colors

Black

Frameset

Frame ConstructionTIG-welded
Frame MaterialTrue Temper OX2
ForkMarzocchi Bomber Z-4, 3.15" travel
Fork MaterialAluminum, triple-clamp crown

Drivetrain

Component GroupMountain Mix
ShiftersShimano Deore
Front DerailleurShimano Deore
Rear DerailleurShimano Deore LX SGS
CranksetShimano Deore, 22/32/42 teeth
Bottom BracketTien Hsin BB-7418
Rear Cogs9-speed, 11 - 32 teeth
ChainKMC Z9000, 1/2 x 3/32"
PedalsPowertools clipless

Brakes

BrakesRST DX-1 Disc Brake brakes, Power Tools Alloy levers

Cockpit & Contact Points

HeadsetTioga TG
HandlebarKore Lite Bar 1
Handlebar ExtensionsNot included
StemKore Lite Forged
SaddleKHS Padded
SeatpostKalloy SP-267

Wheels & Tires

HubsAlloy disc
RimsMavic X317 Disc
SpokesStainless steel, double-butted
Front TireWTB Racing Raptor kevlar

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes42/32/22T · 11–32T · 9-speed
Lowest0.69:1 Highest3.82:1 Total range555%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
KMC Z9000

1/2 x 3/32"

Crankset · Original
Shimano Deore

22/32/42 teeth

Front derailleur · Original
Shimano Deore
More parts (4)Fewer parts
Rear derailleur · Original
Shimano Deore LX SGS
Shifters · Original
Shimano Deore
Seatpost · Original
Kalloy SP-267
Rims · Original
Mavic X317 Disc

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
WTB Racing Raptor kevlar
Drivetrain
9-speed
Bottom bracket / shell
Tien Hsin BB-7418
Campaign
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 13 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Marzocchi Bomber Z-4, 3.15" travel · Aluminum, triple-clamp crown

Archived: Fork: Marzocchi Bomber Z-4, 3.15" travel

Archived: Group: Mountain Mix · Shifters: Shimano Deore · Front derailleur: Shimano Deore · Rear derailleur: Shimano Deore LX SGS · Crankset: Shimano Deore, 22/32/42 teeth · Bottom bracket: Tien Hsin BB-7418 · Rear cogs: 9-speed, 11 - 32 teeth · Chain: KMC Z9000, 1/2 x 3/32"

Archived: Brakes: RST DX-1 Disc Brake brakes, Power Tools Alloy levers

Archived: Rims: Mavic X317 Disc · Hubs: Alloy disc · Front tire: WTB Racing Raptor kevlar

Controls and contact points

Archived: Headset: Tioga TG · Handlebar: Kore Lite Bar 1 · Stem: Kore Lite Forged · Seatpost: Kalloy SP-267 · Saddle: KHS Padded · Pedals: Powertools clipless
