1997 KHS FXT Comp

Archived: Frame: TIG-welded · Fork: Rock Shox Indy XC · Magnesium, triple-clamp crown

• Inspect the complete frame for cracks, dents, distortion, heavy abrasion, suspicious paint differences or evidence of a previous repair.
• Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Archived: Fork: Rock Shox Indy XC · Rear shock: Shock Works, 5.0" travel

• Inspect the shock shaft and seals, cycle the rear suspension through its travel and check for oil, air loss, binding or unusual top-out and bottom-out noises.
• Hold the rear brake and load the suspension from several directions. Check pivots, bearings and mounting hardware for knock, looseness or side play.
• Ask for dated shock and pivot-service records. A clean exterior does not establish the condition of internal seals, oil, bushings or bearings.

Archived: Group: Shimano Deore LX · Shifters: Shimano Deore LX RapidFire SL · Front derailleur: Shimano STX-RC top-swing, top-pull/clamp-on 31.8 mm · Rear derailleur: Shimano Deore LX SGS · Crankset: SR Apex 450, 22/32/42 teeth · Bottom bracket: Shimano BB-UN52 · Rear cogs: 8-speed, 11 - 28 teeth · Chain: KMC SS-91S, 1/2 x 3/32"

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Shimano Deore LX V-Brake brakes, Shimano Deore LX levers

• Inspect pads, cables and housings, then examine both rim braking surfaces for concavity, cracking or heavy wear. Confirm each caliper returns and centers correctly.

Archived: Wheel size: 26" wheels · Rims: WTB SpeedMaster, 32-hole · Hubs: Front: Shimano STX-RC suspension, Rear: Shimano STX-RC · Front tire: 26 x 2.10" WTB Primal Raptor

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Archived: Headset: 1 1/8" threadless Dia-Compe Aheadset · Handlebar: Alico 4C-006 · Stem: Aluminum · Seatpost: Polygon PM-312, 26.8 mm diameter · Saddle: Selle San Marco Tecno Dynamica · Pedals: Aluminum cage w/clips & straps

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
