Lowest1.00:1
Highest3.69:1
Total range369%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×1.95; rear size isn’t listed.
Velopedia Bicycle Archive
1995 KHS Montana Trail
Original specifications: Shimano Altus C90 drivetrain · 26" wheels · 30.4 lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #32363- Model year
- 1995
- Category
- Mountain
- Original MSRP
- $259.00
- Sizes
- 15", 17", 19", 21", womens 17"
- Colors
- Cabernet, White
- Weight
- 30.4 lb
- Geometry
- Legacy reference
- In this record
- 25 specifications · original MSRP · geometry
Model history 4 other years
Browse other years
Compare side by side
Identification clues
1995 archived details
- Published colors
- Cabernet, White
- Frame
- Hi-tensile steel, True Temper chromoly downtube
- Original equipment
- Shimano Altus C90
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHi-tensile steel, True Temper chromoly downtube · Shimano Altus C90 · 26" wheels
Frameset
| Frame Construction | TIG-welded steel |
|---|---|
| Frame Material | Hi-tensile steel, True Temper chromoly downtube |
| Fork | Spinner |
| Fork Material | Hi-tensile steel, unicrown crown |
Drivetrain
| Component Group | Shimano Altus C90 |
|---|---|
| Shifters | Suntour ErgoTwist TS-ET15 |
| Front Derailleur | Shimano Tourney TY-30, bottom-pull/clamp-on 28.6 mm |
| Rear Derailleur | Shimano Altus C90 |
| Crankset | Tracer MT-3i, 28/38/48 teeth |
| Rear Cogs | 7-speed, 13 - 28 teeth |
| Chain | Shimano CN-UG50, 1/2 x 3/32" |
| Pedals | Victor VP-872 |
Brakes
| Brakes | Chang Star 877AT brakes, Suntour TS-ET15 levers |
|---|
Cockpit & Contact Points
| Headset | 1" Tien Hsin TH-390 |
|---|---|
| Handlebar | Steel |
| Handlebar Extensions | Not included |
| Stem | Steel |
| Saddle | Selle Master |
| Seatpost | Steel, 25.6 mm diameter |
Wheels & Tires
| Hubs | King Kong Q/R |
|---|---|
| Rims | Femco A5, 36-hole |
| Spokes | Stainless steel, straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 1.95" Cheng Shin C-1027 |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 530 mm |
| Head-tube angle | 70° |
| Seat-tube angle | 73° |
| Chainstay / rear center | 430 mm |
| Wheelbase | 1040 mm |
| Fork offset / rake | 45 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
26 x 1.95" Cheng Shin C-1027
Replacement search: 26x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
Shimano Altus C90
More parts (1)Fewer parts
Steel
25.6 mm diameter
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 1.95" Cheng Shin C-1027
- Drivetrain
- 7-speed
- Seatpost diameter
- 25.6 mm
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded steel · Fork: Spinner · Hi-tensile steel, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano Altus C90 · Shifters: Suntour ErgoTwist TS-ET15 · Front derailleur: Shimano Tourney TY-30, bottom-pull/clamp-on 28.6 mm · Rear derailleur: Shimano Altus C90 · Crankset: Tracer MT-3i, 28/38/48 teeth · Rear cogs: 7-speed, 13 - 28 teeth · Chain: Shimano CN-UG50, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Chang Star 877AT brakes, Suntour TS-ET15 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Femco A5, 36-hole · Hubs: King Kong Q/R · Front tire: 26 x 1.95" Cheng Shin C-1027
Controls and contact points
Archived: Headset: 1" Tien Hsin TH-390 · Handlebar: Steel · Stem: Steel · Seatpost: Steel, 25.6 mm diameter · Saddle: Selle Master · Pedals: Victor VP-872
