Lowest0.73:1
Highest3.82:1
Total range521%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×1.95; rear size isn’t listed.
Velopedia Bicycle Archive
2003 K2 Zed 2.0
Original specifications: Shimano Alivio · 8-speed · mechanical rear derailleur · 26" wheels.
Planning to sell? Draft your listing
At a glance
Archive #38716- Model year
- 2003
- Category
- Mountain
- Original MSRP
- $400.00
- Sizes
- L, M, S, way big
- Colors
- Black/Copper, Red/Silver
- In this record
- 27 specifications · archived image · original MSRP
Model history 4 other years
Browse other years
Compare side by side
Identification clues
2003 archived details
- Published colors
- Black/Copper, Red/Silver
- Frame
- 6061 T6 aluminum
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 T6 aluminum · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | Answer Manitou Six, 80mm travel |
| Fork Material | Aluminum/magnesium, single crown |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Acera EF35 |
| Front Derailleur | Shimano Altus, clamp-on/31.8mm |
| Rear Derailleur | Shimano Alivio |
| Crankset | Suntour XCC-150, 22/32/42 teeth |
| Bottom Bracket | Cartridge |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 30 teeth |
| Chain | KMC IG-31, 1/2 x 3/32" |
| Pedals | Steel cage w/clips & straps |
Brakes
| Brakes | Tektro linear-pull brakes, Shimano Acera levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Ritchey |
|---|---|
| Handlebar | Aluminum, rise |
| Handlebar Extensions | Not included |
| Stem | Aluminum threadless |
| Saddle | WTB SST X2 |
| Seatpost | Aluminum micro-adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | Formula aluminum disc, Q/R |
|---|---|
| Rims | Ritchey Girder, 36-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 1.95" IRC Multi-Terrain |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Aluminum micro-adjust
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
26 x 1.95" IRC Multi-Terrain
Tektro linear-pull brakes
Shimano Acera levers
More parts (5)Fewer parts
WTB SST X2
Shimano Altus
clamp-on/31.8mm
Shimano Alivio
Shimano Acera EF35
Ritchey Girder
36-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 1.95" IRC Multi-Terrain
- Drivetrain
- 8-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Cartridge · 68mm English
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Answer Manitou Six, 80mm travel · Aluminum/magnesium, single crown
Suspension
Evaluate the suspension →Archived: Fork: Answer Manitou Six, 80mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano Acera EF35 · Front derailleur: Shimano Altus, clamp-on/31.8mm · Rear derailleur: Shimano Alivio · Crankset: Suntour XCC-150, 22/32/42 teeth · Bottom bracket: Cartridge · Rear cogs: 8-speed, 11 - 30 teeth · Chain: KMC IG-31, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro linear-pull brakes, Shimano Acera levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Ritchey Girder, 36-hole · Hubs: Formula aluminum disc, Q/R · Front tire: 26 x 1.95" IRC Multi-Terrain
Controls and contact points
Archived: Headset: 1 1/8" threadless Ritchey · Handlebar: Aluminum, rise · Stem: Aluminum threadless · Seatpost: Aluminum micro-adjust, 27.2mm diameter · Saddle: WTB SST X2 · Pedals: Steel cage w/clips & straps
