2003 K2 Zed 1.0
Mountain bike, front suspension bicycle from the Velopedia specification archive.
- Original MSRP
- $300.00
- Sizes
- Large, medium, small, way big
- Colors
- Red/Silver, White/Blue
- Archive ID
- 38715
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | Noleen Comp FS, 70mm travel |
| Fork Material | Aluminum, single crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Acera EF35 |
| Front Derailleur | Shimano Altus, clamp-on |
| Rear Derailleur | Shimano Alivio |
| Crankset | Suntour XCC-150, 22/32/42 teeth |
| Bottom Bracket | Cartridge |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 11 - 30 teeth |
| Chain | KMC IG-31, 1/2 x 3/32" |
| Pedals | Resin |
Brakes
| Brakes | Tektro linear-pull brakes, Shimano Acera levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Ritchey |
|---|---|
| Handlebar | Steel, 30mm rise |
| Handlebar Extensions | Not included |
| Stem | Aluminum threadless |
| Saddle | WTB SST X2 |
| Seatpost | Aluminum micro-adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | Formula aluminum disc, Q/R |
|---|---|
| Rims | Alex Y-2000, 36-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Front Tire | 26 x 1.95" IRC Multi-Terrain |
| Wheel Size | 26" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
