Lowest0.69:1
Highest4.00:1
Total range582%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×38; rear size isn’t listed.
Velopedia Bicycle Archive
2003 K2 Newport
Original specifications: Hybrid Mix drivetrain · 700c wheels.
Planning to sell? Draft your listing
At a glance
Archive #38784- Model year
- 2003
- Category
- Hybrid
- Original MSRP
- $430.00
- Sizes
- L, M, S, way big, women's
- Colors
- Silver/Gray Chrome
- In this record
- 27 specifications · archived image · original MSRP
Model history 5 other years
Browse other years
Compare side by side
Identification clues
2003 archived details
- Published colors
- Silver/Gray Chrome
- Frame
- 6061 T6 aluminum
- Original equipment
- Hybrid Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original build6061 T6 aluminum · Hybrid Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork | Noleen NS-3 |
| Fork Material | Aluminum, single crown |
Drivetrain
| Component Group | Hybrid Mix |
|---|---|
| Shifters | SRAM ESP 5.0 |
| Front Derailleur | Shimano Deore |
| Rear Derailleur | SRAM ESP 5.0 |
| Crankset | Suntour XCC-310, 22/32/44 teeth |
| Bottom Bracket | Cartridge |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | SRAM PC-49, 1/2 X 3/32" |
| Pedals | K2 Comfort Tech |
Brakes
| Brakes | Tektro linear-pull brakes, alloy levers |
|---|
Cockpit & Contact Points
| Headset | 1" steel |
|---|---|
| Handlebar | Aluminum, 1.25" rise |
| Handlebar Extensions | Not included |
| Stem | Aluminum, adjustable |
| Saddle | K2 ComfortTech |
| Seatpost | Aluminum, suspension |
Wheels & Tires
| Hubs | Shimano Alivio |
|---|---|
| Rims | Weinmann Zac 19, 32-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 38c multi-terrain |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 38c multi-terrain
Replacement search: 700cx38 bicycle tire Before ordering: Check rim type and tire clearance.
Tektro linear-pull brakes
alloy levers
More parts (2)Fewer parts
Shimano Deore
Shimano Alivio
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 38c multi-terrain
- Drivetrain
- 9-speed
- Bottom bracket / shell
- Cartridge · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Noleen NS-3 · Aluminum, single crown
Drivetrain
Check drivetrain wear →Archived: Group: Hybrid Mix · Shifters: SRAM ESP 5.0 · Front derailleur: Shimano Deore · Rear derailleur: SRAM ESP 5.0 · Crankset: Suntour XCC-310, 22/32/44 teeth · Bottom bracket: Cartridge · Rear cogs: 9-speed, 11 - 32 teeth · Chain: SRAM PC-49, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Tektro linear-pull brakes, alloy levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Weinmann Zac 19, 32-hole · Hubs: Shimano Alivio · Front tire: 700 x 38c multi-terrain
Controls and contact points
Archived: Headset: 1" steel · Handlebar: Aluminum, 1.25" rise · Stem: Aluminum, adjustable · Seatpost: Aluminum, suspension · Saddle: K2 ComfortTech · Pedals: K2 Comfort Tech
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
