Velopedia Bicycle Archive

1999 K2 Zed V

Original specifications: Shimano STX RC · 8-speed · mechanical rear derailleur · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #87629
Model year
1999
Category
Mountain
Original MSRP
$699.00
Sizes
L, M, S, way big
Colors
Black
In this record
27 specifications · original MSRP
Model history 1 other year

Browse other years

Compare side by side

Identification clues

1999 archived details

Published colors
Black
Frame
K2 7005
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildK2 7005 · Mountain Mix · 26" wheels

Manufacturer catalog

Published sizes and colors

4 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

LMSway big

Published colors

Black

Frameset

Frame ConstructionTIG-welded
Frame MaterialK2 7005
ForkRST Zeta EL, 2.5" travel
Fork MaterialChromoly, triple-clamp crown

Drivetrain

Component GroupMountain Mix
ShiftersShimano Alivio RapidFire SL
Front DerailleurShimano Alivio, bottom-pull/clamp-on 31.8mm
Rear DerailleurShimano STX-RC
CranksetShimano STX-RC, 22/32/42 teeth
Bottom BracketShimano, 110mm spindle
BB Shell Width68mm English
Rear Cogs8-speed, 11 - 32 teeth
ChainKMC IG-31, 1/2 x 3/32"
PedalsWellgo LU-908A w/clips & straps

Brakes

BrakesTektro linear-pull brakes, Tektro levers

Cockpit & Contact Points

Headset1 1/8" threadless Tange-Seiki Aheadset
HandlebarK2 butted alloy
Handlebar ExtensionsTIG alloy
StemK2 TIG alloy
SaddleK2 w/grey guards
SeatpostK2 flex post, 27.2mm diameter

Wheels & Tires

HubsShimano Alivio
RimsWeinmann Zac 19, 32-hole
SpokesMarwi stainless steel, 1.8mm straight gauge
Spoke NipplesAlloy nipples
Front Tire26 x 2.10" Kenda Kinetic
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build42/32/22T · 11–32T · 8-speed
Lowest0.69:1 Highest3.82:1 Total range555%
Estimated speed At 90 RPM Lowest gear4.8 mph Highest gear26.8 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
26 x 2.10" Kenda Kinetic
Brake pads · Original
Tektro linear-pull brakes

Tektro levers

More parts (5)Fewer parts
Pedals · Original
Wellgo LU-908A w/clips & straps
Crankset · Original
Shimano STX-RC

22/32/42 teeth

Rear derailleur · Original
Shimano STX-RC
Shifters · Original
Shimano Alivio RapidFire SL
Hubs · Original
Shimano Alivio

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" Kenda Kinetic
Drivetrain
8-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Shimano, 110mm spindle · 68mm English
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: RST Zeta EL, 2.5" travel · Chromoly, triple-clamp crown

Archived: Fork: RST Zeta EL, 2.5" travel

Archived: Group: Mountain Mix · Shifters: Shimano Alivio RapidFire SL · Front derailleur: Shimano Alivio, bottom-pull/clamp-on 31.8mm · Rear derailleur: Shimano STX-RC · Crankset: Shimano STX-RC, 22/32/42 teeth · Bottom bracket: Shimano, 110mm spindle · Rear cogs: 8-speed, 11 - 32 teeth · Chain: KMC IG-31, 1/2 x 3/32"

Archived: Brakes: Tektro linear-pull brakes, Tektro levers

Archived: Wheel size: 26" wheels · Rims: Weinmann Zac 19, 32-hole · Hubs: Shimano Alivio · Front tire: 26 x 2.10" Kenda Kinetic

Controls and contact points

Archived: Headset: 1 1/8" threadless Tange-Seiki Aheadset · Handlebar: K2 butted alloy · Stem: K2 TIG alloy · Seatpost: K2 flex post, 27.2mm diameter · Saddle: K2 w/grey guards · Pedals: Wellgo LU-908A w/clips & straps
