2014 Jamis Nova Pro

Original specifications.

Share owner experience

At a glance

Archive #9258300

Model year: 2014
Sizes: 48, 51, 54, 56, 58, 61
Colors: Ano Black/Victory Blue
In this record: 14 specifications · archived image

Model history 4 other years

Browse other years

Compare side by side

Identification clues

2014 archived details

Published colors: Ano Black/Victory Blue
Frame: 7005 Aluminum

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build7005 Aluminum

Manufacturer catalog

Published sizes and colors

6 sizes · 1 color

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

485154565861

Published colors

Ano Black/Victory Blue

Frameset

Frame Material	7005 Aluminum
Fork	Carbon

Drivetrain

Shifters	SRAM Apex
Crankset	SRAM S350 346/36t
Bottom Bracket	SRAM PressFit 30
Cassette	SRAM PG1030 10-Speed 11-28T
Chain	SRAM PC1031 w/Powerlock

Brakes

Brakes	TRP HYRD Disc

Cockpit & Contact Points

Headset	1 1/8" Top 1 1/2" Lower
Handlebar	Ritchey Comp Logic
Stem	Ritchey Comp
Saddle	Selle San Marco SPID Open
Seatpost	Ritchey Road

Wheels & Tires

Front Tire	Clement Crusade PDX 700x33

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Original size / build

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Chain · Original

SRAM PC1031 w/Powerlock

Search Amazon Search eBay

Retailer offers

SRAM PC 1031 Chain One Color, 114 Links / 10-Speed

Model match

Competitive Cyclist ↗$28.00

Stem · Original

Ritchey Comp

Search Amazon Search eBay

Retailer offers

Ritchey Comp 4-Axis 30D Stem Black, 70mm, -30 deg

Model match

Competitive Cyclist ↗$48.35

Cassette · Original

SRAM PG1030 10-Speed 11-28T

Search Amazon Search eBay

More parts (5)Fewer parts

Front tire · Original

Clement Crusade PDX 700x33 Replacement search: 700cx33 bicycle tire Before ordering: Check rim type and tire clearance.

Search Amazon Search eBay

Bottom bracket · Original

SRAM PressFit 30

Search Amazon Search eBay

Crankset · Original

SRAM S350 346/36t

Search Amazon Search eBay

Shifters · Original

SRAM Apex Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.

Search Amazon Search eBay

Handlebar · Original

Ritchey Comp Logic

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: Clement Crusade PDX 700x33
Drivetrain: 10-speed
Bottom bracket / shell: SRAM PressFit 30

Equipment inspection checks 8 checks based on 4 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: 7005 Aluminum · Fork: Carbon

Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.
Inspect the fork crown, blades, dropouts and visible steerer area. Check that it is straight, securely installed and free of cracks or impact damage.

Drivetrain

Check drivetrain wear →

Archived: Shifters: SRAM Apex · Crankset: SRAM S350 346/36t · Bottom bracket: SRAM PressFit 30 · Cassette: SRAM PG1030 10-Speed 11-28T · Chain: SRAM PC1031 w/Powerlock

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: TRP HYRD Disc

Inspect pads, rotors, calipers and the complete cable or hose path. Both levers should feel consistent and both calipers should release without persistent rubbing.

Controls and contact points

Archived: Headset: 1 1/8" Top 1 1/2" Lower · Handlebar: Ritchey Comp Logic · Stem: Ritchey Comp · Seatpost: Ritchey Road · Saddle: Selle San Marco SPID Open

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
