2009 Jamis Laser 1.6

Original specifications: Juvenile Mix drivetrain · 16" wheels · 27.8 lb published weight.

Share owner experience

At a glance

Archive #17946

Model year: 2009
Category: Kids
Original MSRP: $190.00
Colors: Glitter Red/Gloss White, Starfire Blue/Gloss White
Weight: 27.8 lb
In this record: 21 specifications · archived image · original MSRP

Model history 5 other years

Browse other years

Compare side by side

Identification clues

2009 archived details

Published colors: Glitter Red/Gloss White, Starfire Blue/Gloss White
Frame: Aluminum
Original equipment: Juvenile Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum · Juvenile Mix · 16" wheels

Historical catalog variants

Archived sizes and colors

2 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published colors

Glitter Red/Gloss WhiteStarfire Blue/Gloss White

View 2 archived size/color combinations

Size	Color
—	Glitter Red/Gloss White
—	Starfire Blue/Gloss White

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame Construction	TIG-welded
Frame Material	Aluminum
Fork Material	High-tensile steel, unicrown crown

Drivetrain

Component Group	Juvenile Mix
Crankset	Cold-forged steel, 36 teeth
Bottom Bracket	VP-B35
Rear Cogs	1-speed
Chain	KMC Z410
Pedals	BMX resin

Brakes

Brakes	Coaster brake rear

Cockpit & Contact Points

Headset	1" Standard threaded type
Handlebar	BMX style
Handlebar Extensions	Not included
Stem	BMX Alloy
Saddle	Jamis Jr BMX
Seatpost	Pillar, 28.6mm diameter

Wheels & Tires

Hubs	Front: Steel Nutted, Rear: Hi Stop coaster brake
Rims	Alloy, 28-hole
Spokes	Nickel-plated, 14ga. (2.0mm)
Front Tire	16 x 2.125" CST Dirt Knobbies
Wheel Size	16" wheels

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

16 x 2.125" CST Dirt Knobbies

Search Amazon Search eBay

Seatpost · Original

Pillar

28.6mm diameter

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 16 x 2.125" CST Dirt Knobbies
Drivetrain: 1-speed
Seatpost diameter: 28.6 mm
Bottom bracket / shell: VP-B35

Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: · High-tensile steel, unicrown crown

Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.

Drivetrain

Check drivetrain wear →

Archived: Group: Juvenile Mix · Crankset: Cold-forged steel, 36 teeth · Bottom bracket: VP-B35 · Rear cogs: 1-speed · Chain: KMC Z410

Check chain tension and chainline, rotate the drivetrain through a full revolution and confirm the rear axle or tensioning hardware cannot slip.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Coaster brake rear

Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 16" wheels · Rims: Alloy, 28-hole · Hubs: Front: Steel Nutted, Rear: Hi Stop coaster brake · Front tire: 16 x 2.125" CST Dirt Knobbies

Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Controls and contact points

Archived: Headset: 1" Standard threaded type · Handlebar: BMX style · Stem: BMX Alloy · Seatpost: Pillar, 28.6mm diameter · Saddle: Jamis Jr BMX · Pedals: BMX resin

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
