Lowest1.30:1
Highest4.33:1
Total range332%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×23; rear size isn’t listed.
Velopedia Bicycle Archive
1998 Jamis Quest
Original specifications: Shimano 105SC drivetrain · 700c wheels · legacy reference geometry.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #72018- Model year
- 1998
- Category
- Road
- Original MSRP
- $1,029.95
- Sizes
- 50 cm, 53 cm, 55 cm, 57 cm, 59 cm, 61 cm
- Colors
- Black
- Geometry
- Legacy reference
- In this record
- 26 specifications · original MSRP · geometry
Model history 18 other years
Browse other years
Compare side by side
Identification clues
1998 archived details
- Published colors
- Black
- Frame
- Reynolds 631
- Original equipment
- Shimano 105SC
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildReynolds 631 · Shimano 105SC · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Reynolds 631 |
| Fork | Jamis |
| Fork Material | Chromoly, unicrown crown |
Drivetrain
| Component Group | Shimano 105SC |
|---|---|
| Shifters | Shimano 105SC STI Dual Control |
| Front Derailleur | Shimano 105SC, bottom-pull/clamp-on 28.6mm |
| Rear Derailleur | Shimano 105SC GS |
| Crankset | Shimano RX-100, 30/42/52 teeth |
| Bottom Bracket | Shimano BB-UN52, 118mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 8-speed, 12 - 23 teeth |
| Chain | Shimano CN-HG70, 1/2 x 3/32" |
| Pedals | Wellgo RC-9701 clipless |
Brakes
| Brakes | Shimano 105SC Dual Pivot brakes, Shimano 105SC levers |
|---|
Cockpit & Contact Points
| Headset | 1" Tange-Seiki Levin |
|---|---|
| Handlebar | Hsin Lung aluminum |
| Stem | Kalloy aluminum |
| Saddle | SDG Ventura Comp, titanium rails |
| Seatpost | Kalloy aluminum micro-adjust, 27.0mm diameter |
Wheels & Tires
| Hubs | Shimano 105SC |
|---|---|
| Rims | Mavic CXP 14, 32-hole |
| Spokes | Wheelsmith stainless steel, 2.0mm double-butted |
| Spoke Nipples | Alloy nipples |
| Front Tire | 700 x 23c Continental Super Sport Ultra |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 550 mm |
| Head-tube angle | 73° |
| Seat-tube angle | 73° |
| Chainstay / rear center | 413 mm |
| Wheelbase | 987 mm |
| Fork offset / rake | 45 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Shimano CN-HG70
1/2 x 3/32"
Retailer offers
SRAM PC-830 Chain One Color, 8 Speed
Replacement option
Shimano CN-HG70 on eBaySponsored links
700 x 23c Continental Super Sport Ultra
Retailer offers
Vittoria Rubino Pro G2.0 Clincher Tire Black, 700x23
700x23c
Replacement option
Continental Super Sport on eBaySponsored links
Shimano BB-UN52
118mm spindle
More parts (5)Fewer parts
Wellgo RC-9701 clipless
SDG Ventura Comp
titanium rails
Kalloy aluminum micro-adjust
27.0mm diameter
Mavic CXP 14
32-hole
Shimano 105SC
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 23c Continental Super Sport Ultra
- Drivetrain
- 8-speed
- Seatpost diameter
- 27 mm
- Bottom bracket / shell
- Shimano BB-UN52, 118mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Jamis · Chromoly, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano 105SC · Shifters: Shimano 105SC STI Dual Control · Front derailleur: Shimano 105SC, bottom-pull/clamp-on 28.6mm · Rear derailleur: Shimano 105SC GS · Crankset: Shimano RX-100, 30/42/52 teeth · Bottom bracket: Shimano BB-UN52, 118mm spindle · Rear cogs: 8-speed, 12 - 23 teeth · Chain: Shimano CN-HG70, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Shimano 105SC Dual Pivot brakes, Shimano 105SC levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mavic CXP 14, 32-hole · Hubs: Shimano 105SC · Front tire: 700 x 23c Continental Super Sport Ultra
Controls and contact points
Archived: Headset: 1" Tange-Seiki Levin · Handlebar: Hsin Lung aluminum · Stem: Kalloy aluminum · Seatpost: Kalloy aluminum micro-adjust, 27.0mm diameter · Saddle: SDG Ventura Comp, titanium rails · Pedals: Wellgo RC-9701 clipless
