2007 Iron Horse 7Point7

Original specifications: SRAM X0 · 9-speed · mechanical rear derailleur · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #94841
Model year
2007
Category
Mountain
Sizes
15", 17", 19"
In this record
27 specifications · archived image
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2007 archived details

Frame
Aluminum
Original equipment
SRAM X.0/mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum · SRAM X.0/mix · 26" wheels

Historical catalog variants

Archived sizes and colors

3 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

15"17"19"
View 3 archived size/color combinations
SizeColor
15"—
17"—
19"—

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialAluminum
ForkRock Shox Totem 2-Stem Air, 180mm travel
Fork MaterialAluminum/magnesium, single crown
Rear ShockFox DHX Coil 5.0, 7" travel

Drivetrain

Component GroupSRAM X.0/mix
ShiftersSRAM X.0 Trigger
Front DerailleurShimano Saint W/ E13 DRS Guide
Rear DerailleurSRAM X.0 Mid Cage
CranksetRace Face Diabolus, 24/36 teeth
Bottom BracketRace Face Diabolus X-Type
BB Shell Width83mm English
Rear Cogs9-speed, 11 - 34 teeth
ChainSRAM PC-971 with Power Link
PedalsCrank Brothers 5050xx

Brakes

BrakesAvid Code w/ 8" Rotor brakes, Avid Code levers

Cockpit & Contact Points

Headset1.5" Integrated FSA Orbit Extreme
HandlebarFunn Fatboy
Handlebar ExtensionsNot included
StemThomson Elite X4
SaddleSDG Bel Air ST I-Beam
SeatpostSDG 2014 I-Beam, 30.0mm diameter

Wheels & Tires

HubsDT Swiss 340
RimsDT Swiss FR6.1D, 32-hole
SpokesDT Swiss Competition, 14/15/14ga. (2.0/1.8/2.0mm)
Front Tire26 x 2.50" Maxxis Minion DHF 3C
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes36/24T · 11–34T · 9-speed
Lowest0.71:1 Highest3.27:1 Total range464%
Estimated speed At 90 RPM Lowest gear5.1 mph Highest gear23.7 mph

Uses front tire 26×2.5; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
SRAM PC-971 with Power Link
Front tire · Original
26 x 2.50" Maxxis Minion DHF 3C
Bottom bracket · Original
Race Face Diabolus X-Type
More parts (9)Fewer parts
Saddle · Original
SDG Bel Air ST I-Beam
Crankset · Original
Race Face Diabolus

24/36 teeth

Front derailleur · Original
Shimano Saint W/ E13 DRS Guide
Rear derailleur · Original
SRAM X.0 Mid Cage
Shifters · Original
SRAM X.0 Trigger
Stem · Original
Thomson Elite X4
Seatpost · Original
SDG 2014 I-Beam

30.0mm diameter

Headset · Original
1.5" Integrated FSA Orbit Extreme
Rims · Original
DT Swiss FR6.1D

32-hole

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.50" Maxxis Minion DHF 3C
Drivetrain
9-speed
Seatpost diameter
30 mm
Bottom bracket / shell
Race Face Diabolus X-Type · 83mm English
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 13 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Rock Shox Totem 2-Stem Air, 180mm travel · Aluminum/magnesium, single crown

Archived: Fork: Rock Shox Totem 2-Stem Air, 180mm travel · Rear shock: Fox DHX Coil 5.0, 7" travel

Archived: Group: SRAM X.0/mix · Shifters: SRAM X.0 Trigger · Front derailleur: Shimano Saint W/ E13 DRS Guide · Rear derailleur: SRAM X.0 Mid Cage · Crankset: Race Face Diabolus, 24/36 teeth · Bottom bracket: Race Face Diabolus X-Type · Rear cogs: 9-speed, 11 - 34 teeth · Chain: SRAM PC-971 with Power Link

Archived: Brakes: Avid Code w/ 8" Rotor brakes, Avid Code levers

Archived: Wheel size: 26" wheels · Rims: DT Swiss FR6.1D, 32-hole · Hubs: DT Swiss 340 · Front tire: 26 x 2.50" Maxxis Minion DHF 3C

Controls and contact points

Archived: Headset: 1.5" Integrated FSA Orbit Extreme · Handlebar: Funn Fatboy · Stem: Thomson Elite X4 · Seatpost: SDG 2014 I-Beam, 30.0mm diameter · Saddle: SDG Bel Air ST I-Beam · Pedals: Crank Brothers 5050xx
