2006 Iron Horse Triumph

Original specifications: Road mix drivetrain · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #11032
Model year
2006
Category
Road
Sizes
47CM, 50CM, 52CM, 54CM, 56CM, 58CM, 61CM
Colors
Grey
In this record
25 specifications
Model history 4 other years

Browse other years

Compare side by side

Identification clues

2006 archived details

Published colors
Grey
Frame
Aluminum
Original equipment
Road mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum · Road mix · 700c wheels

Historical catalog variants

Archived sizes and colors

7 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

47CM50CM52CM54CM56CM58CM61CM

Published colors

Grey
View 7 archived size/color combinations
SizeColor
47CMGrey
50CMGrey
52CMGrey
54CMGrey
56CMGrey
58CMGrey
61CMGrey

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialAluminum
ForkIron Horse
Fork MaterialChromoly

Drivetrain

Component GroupRoad mix
ShiftersSRAM TRX Triggers
Front DerailleurShimano 2203
Rear DerailleurShimano 2200
CranksetRPM CRD Triple, 30/42/52 teeth
Bottom BracketSealed Cartridge
Rear Cogs8-speed, 12 - 24 teeth
ChainShimano CN-HG50, 1/2 x 3/32"
PedalsWellgo Alloy W/ Toeclip & Strap

Brakes

BrakesTektro Road brakes, Tektro levers

Cockpit & Contact Points

Headset1 1/8" integrated Integrated Alloy
HandlebarFlat Alloy
Handlebar ExtensionsNot included
StemAlloy Adjustable
SaddleVelo Road
SeatpostAluminum, micro-adjust

Wheels & Tires

HubsAluminum, Q/R
RimsAlex aluminum, 32-hole
SpokesStainless steel, 14ga. (2.0mm) straight gauge
Front Tire700 x 26C Kenda Kontender
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes52/42/30T · 12–24T · 8-speed
Lowest1.25:1 Highest4.33:1 Total range347%
Estimated speed At 90 RPM Lowest gear8.9 mph Highest gear30.8 mph

Uses front tire 700C×26; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
Shimano CN-HG50

1/2 x 3/32"

Front tire · Original
700 x 26C Kenda Kontender
Pedals · Original
Wellgo Alloy W/ Toeclip & Strap

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 26C Kenda Kontender
Drivetrain
8-speed
Bottom bracket / shell
Sealed Cartridge
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Iron Horse · Chromoly

Archived: Group: Road mix · Shifters: SRAM TRX Triggers · Front derailleur: Shimano 2203 · Rear derailleur: Shimano 2200 · Crankset: RPM CRD Triple, 30/42/52 teeth · Bottom bracket: Sealed Cartridge · Rear cogs: 8-speed, 12 - 24 teeth · Chain: Shimano CN-HG50, 1/2 x 3/32"

Archived: Brakes: Tektro Road brakes, Tektro levers

Archived: Wheel size: 700c wheels · Rims: Alex aluminum, 32-hole · Hubs: Aluminum, Q/R · Front tire: 700 x 26C Kenda Kontender

Controls and contact points

Archived: Headset: 1 1/8" integrated Integrated Alloy · Handlebar: Flat Alloy · Stem: Alloy Adjustable · Seatpost: Aluminum, micro-adjust · Saddle: Velo Road · Pedals: Wellgo Alloy W/ Toeclip & Strap
