2005 Haro Extreme X3

Original specifications: Shimano Deore XT · 9-speed · mechanical rear derailleur · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #10152
Model year
2005
Category
Mountain
In this record
27 specifications · archived image
Model history 3 other years

Browse other years

Compare side by side

Identification clues

2005 archived details

Frame
6061 T6 aluminum
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build6061 T6 aluminum · Mountain Mix · 26" wheels

Frameset

Frame ConstructionTIG-welded
Frame Material6061 T6 aluminum
ForkManitou Stance Flow, 120/150mm
Fork MaterialAluminum, single crown
Rear ShockManitou Metel RP Coil w/Piggyback, 7" travel

Drivetrain

Component GroupMountain Mix
ShiftersShimano Deore LX RapidFire
Front DerailleurShimano Deore
Rear DerailleurShimano Deore XT
CranksetTruVativ Hussefelt, 22/32 teeth
Bottom BracketTruVativ Gigapipe Team DH ISIS
Rear Cogs9-speed, 11 - 34 teeth
ChainShimano CN-HG73, 1/2 x 3/32"
PedalsPivit platform

Brakes

BrakesHayes HFX-9 Hydraulic Disc brakes, Hayes Hydraulic levers

Cockpit & Contact Points

Headset1 1/2" integrated FSA Orbit DL
HandlebarTruVativ Hussefelt
Handlebar ExtensionsNot included
StemTruVativ Hussefelt
SaddleSDG I-Beam FRD
SeatpostSDG I-Beam, 30.9mm diameter

Wheels & Tires

HubsFront: Pivit 9 20mm, Rear: Pivit 9 12mm
RimsSun Rims Single Track SL1
SpokesStainless steel, 14ga. (2.0mm) straight gauge
Spoke NipplesBrass nipples
Front Tire26 x 2.50" Maxxis Minion DH
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build32/22T · 11–34T · 9-speed
Lowest0.65:1 Highest2.91:1 Total range450%
Estimated speed At 90 RPM Lowest gear4.7 mph Highest gear21.0 mph

Uses front tire 26×2.5; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
Shimano CN-HG73

1/2 x 3/32"

Front tire · Original
26 x 2.50" Maxxis Minion DH
Saddle · Original
SDG I-Beam FRD
More parts (5)Fewer parts
Front derailleur · Original
Shimano Deore
Rear derailleur · Original
Shimano Deore XT
Shifters · Original
Shimano Deore LX RapidFire
Seatpost · Original
SDG I-Beam

30.9mm diameter

Headset · Original
1 1/2" integrated FSA Orbit DL

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.50" Maxxis Minion DH
Drivetrain
9-speed
Seatpost diameter
30.9 mm
Bottom bracket / shell
TruVativ Gigapipe Team DH ISIS
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 13 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Manitou Stance Flow, 120/150mm · Aluminum, single crown

Archived: Fork: Manitou Stance Flow, 120/150mm · Rear shock: Manitou Metel RP Coil w/Piggyback, 7" travel

Archived: Group: Mountain Mix · Shifters: Shimano Deore LX RapidFire · Front derailleur: Shimano Deore · Rear derailleur: Shimano Deore XT · Crankset: TruVativ Hussefelt, 22/32 teeth · Bottom bracket: TruVativ Gigapipe Team DH ISIS · Rear cogs: 9-speed, 11 - 34 teeth · Chain: Shimano CN-HG73, 1/2 x 3/32"

Archived: Brakes: Hayes HFX-9 Hydraulic Disc brakes, Hayes Hydraulic levers

Archived: Wheel size: 26" wheels · Rims: Sun Rims Single Track SL1 · Hubs: Front: Pivit 9 20mm, Rear: Pivit 9 12mm · Front tire: 26 x 2.50" Maxxis Minion DH

Controls and contact points

Archived: Headset: 1 1/2" integrated FSA Orbit DL · Handlebar: TruVativ Hussefelt · Stem: TruVativ Hussefelt · Seatpost: SDG I-Beam, 30.9mm diameter · Saddle: SDG I-Beam FRD · Pedals: Pivit platform
