2003 Haro TR2.2

Original specifications: 20" wheels · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #38588
Model year
2003
Category
BMX
Original MSRP
$230.00
Sizes
Pro
Colors
Chrome, Putty, SG Black
Geometry
Legacy reference
In this record
23 specifications · archived image · original MSRP · geometry
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2003 archived details

Published colors
Chrome, Putty, SG Black
Frame
Chromoly main triangle/hi-tensile steel rear stays
Original equipment
N/A

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildChromoly main triangle/hi-tensile steel rear stays · 20" wheels

Manufacturer catalog

Published sizes and colors

1 size · 3 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

Pro

Published colors

ChromePuttySG Black

Frameset

Frame ConstructionTIG-welded
Frame MaterialChromoly main triangle/hi-tensile steel rear stays
ForkHaro BMX
Fork MaterialChromoly, unicrown crown

Drivetrain

CranksetHaro Tubular Crmo, 44 teeth
Bottom BracketFusion sealed
BB Shell WidthAmerican
Rear Cogs1-speed, 16 teeth
ChainKMC Z410
PedalsFusion DX style platform, aluminum

Brakes

BrakesTektro alloy U-brake rear brakes, Tektro aluminum rear levers

Cockpit & Contact Points

Headset1 1/8" threadless Tien Hsin Power Pro
HandlebarHaro Slim Bar
StemFusion
SaddleHaro Padded
SeatpostFusion steel pillar

Wheels & Tires

HubsHaro Mid Flange
RimsAlex X-303, 36-hole
SpokesUCP, 13ga. (2.34mm) straight gauge
Spoke NipplesBrass nipples
Front Tire20 x 2.25" Haro Catapult
Rear Tire20 x 2.10" Haro Catapult
Wheel Size20" wheels

Geometry

Legacy reference · 5 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 5 measurements
MeasurementLegacy reference
Top tube508 mm
Head-tube angle74°
Seat-tube angle72°
Chainstay / rear center365 mm
Wheelbase924.1 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build44T · 16T · 1-speed
Ratio2.75:1
Estimated speed At 90 RPM Gear14.9 mph

Rear tire: 20×2.1.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
