1999 Haro Extreme EX2

Original specifications: Shimano Deore XT · 9-speed · mechanical rear derailleur · 26" wheels · 29.4 lb published weight.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #87872
Model year
1999
Category
Mountain
Original MSRP
$1,110.00
Sizes
15.5", 17.5", 19.5"
Colors
Mustard, Polished
Weight
29.4 lb
Geometry
Legacy reference
In this record
28 specifications · archived image · original MSRP · geometry
Model history 1 other year

Browse other years

Compare side by side

Identification clues

1999 archived details

Published colors
Mustard, Polished
Frame
7005 aluminum
Original equipment
Mountain Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build7005 aluminum · Mountain Mix · 26" wheels

Manufacturer catalog

Published sizes and colors

3 sizes · 2 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

15.5"17.5"19.5"

Published colors

MustardPolished

Frameset

Frame ConstructionTIG-welded
Frame Material7005 aluminum
ForkRock Shox Judy C, 3.15" travel
Fork MaterialAluminum/magnesium, triple-clamp crown
Rear ShockRock Shox Coupe Deluxe, 4.0" travel

Drivetrain

Component GroupMountain Mix
ShiftersShimano Deore LX RapidFire SL
Front DerailleurShimano STX-RC top-swing, top-pull/bottom bracket mount
Rear DerailleurShimano Deore XT SGS
CranksetShimano STX-RC, 22/32/42 teeth
Bottom BracketShimano BB-UN52, 107mm spindle
BB Shell Width68mm English
Rear Cogs9-speed, 11 - 32 teeth
ChainShimano CN-HG72, 1/2 x 3/32"
PedalsWellgo WPD-800 clipless

Brakes

BrakesAvid 1D-10 brakes, Shimano Deore LX levers

Cockpit & Contact Points

Headset1 1/8" threadless Aheadset SE-1
HandlebarHaro riser, 2014 aluminum
Handlebar ExtensionsNot included
StemJD aluminum
SaddleWTB SSTK, hollow chromoly rails w/kevlar sides
SeatpostZoom Microset, 31.6mm diameter

Wheels & Tires

HubsShimano Alivio
RimsWTB SpeedMaster, 32-hole
SpokesWTB stainless steel, 2.0mm double-butted
Spoke NipplesBrass nipples
Front Tire26 x 2.10" WTB EnduroRaptor
Wheel Size26" wheels

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube584.2 mm
Head-tube angle70.5°
Seat-tube angle73°
Chainstay / rear center428 mm
Wheelbase1071.9 mm
Fork offset / rake39.1 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes42/32/22T · 11–32T · 9-speed
Lowest0.69:1 Highest3.82:1 Total range555%
Estimated speed At 90 RPM Lowest gear4.8 mph Highest gear26.8 mph

Uses front tire 26×2.1; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Seatpost · Original
Zoom Microset

31.6mm diameter

Chain · Original
Shimano CN-HG72

1/2 x 3/32"

Front tire · Original
26 x 2.10" WTB EnduroRaptor
More parts (8)Fewer parts
Bottom bracket · Original
Shimano BB-UN52

107mm spindle

Pedals · Original
Wellgo WPD-800 clipless
Saddle · Original
WTB SSTK

hollow chromoly rails w/kevlar sides

Crankset · Original
Shimano STX-RC

22/32/42 teeth

Rear derailleur · Original
Shimano Deore XT SGS
Shifters · Original
Shimano Deore LX RapidFire SL
Rims · Original
WTB SpeedMaster

32-hole

Hubs · Original
Shimano Alivio

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.10" WTB EnduroRaptor
Drivetrain
9-speed
Seatpost diameter
31.6 mm
Bottom bracket / shell
Shimano BB-UN52, 107mm spindle · 68mm English
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 13 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Rock Shox Judy C, 3.15" travel · Aluminum/magnesium, triple-clamp crown

Archived: Fork: Rock Shox Judy C, 3.15" travel · Rear shock: Rock Shox Coupe Deluxe, 4.0" travel

Archived: Group: Mountain Mix · Shifters: Shimano Deore LX RapidFire SL · Front derailleur: Shimano STX-RC top-swing, top-pull/bottom bracket mount · Rear derailleur: Shimano Deore XT SGS · Crankset: Shimano STX-RC, 22/32/42 teeth · Bottom bracket: Shimano BB-UN52, 107mm spindle · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG72, 1/2 x 3/32"

Archived: Brakes: Avid 1D-10 brakes, Shimano Deore LX levers

Archived: Wheel size: 26" wheels · Rims: WTB SpeedMaster, 32-hole · Hubs: Shimano Alivio · Front tire: 26 x 2.10" WTB EnduroRaptor

Controls and contact points

Archived: Headset: 1 1/8" threadless Aheadset SE-1 · Handlebar: Haro riser, 2014 aluminum · Stem: JD aluminum · Seatpost: Zoom Microset, 31.6mm diameter · Saddle: WTB SSTK, hollow chromoly rails w/kevlar sides · Pedals: Wellgo WPD-800 clipless
