Lowest0.88:1
Highest4.36:1
Total range499%
Velopedia Bicycle Archive
At a glance
Archive #2023562- Model year
- 2012
- Category
- Hybrid
- Sizes
- S, M, L, XL
- Colors
- Satin Black, Silver
- In this record
- 18 specifications · 2 archived images
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2012 archived details
- Published colors
- Satin Black, Silver
- Frame
- Hydroformed Butted 6061 Al
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHydroformed Butted 6061 Al
Frameset
| Frame Material | Hydroformed Butted 6061 Al |
|---|---|
| Fork | GT Type R w/ 6061 |
Drivetrain
| Shifters | Shimano EF-51 8spd |
|---|---|
| Front Derailleur | Shimano M191 |
| Rear Derailleur | Shimano Acera 8spd |
| Crankset | Shimano M311 48/38/28t |
| Bottom Bracket | FSA Sealed |
| Cassette | Shimano HG-51 8spd 11-32t |
| Chain | KMC HG-40 |
| Pedals | GT Trekking |
Brakes
| Brakes | Tektro RX 1.0 |
|---|
Cockpit & Contact Points
| Headset | Fsa |
|---|---|
| Handlebar | GT Type R Flat-Riser |
| Stem | GT 3D Forged 6061 |
| Saddle | GTw Bio-Morphic |
| Seatpost | GT 2 bolt Alloy Road |
Wheels & Tires
| Hubs | Formula Sealed Formula Sealed |
|---|---|
| Front Tire | Kenda Kwest 700x32 |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
