2000 GT Avalanche

Archived: Frame: TIG-welded · Fork: Rock Shox Judy Race, 2.5"-4.0" adjustable travel · Aluminum/magnesium, triple-clamp crown

• Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.

Archived: Fork: Rock Shox Judy Race, 2.5"-4.0" adjustable travel

• Inspect the fork stanchions for scratches or coating wear, look for oil or dirt rings at the seals, and cycle the fork through its travel while checking for binding or bushing play.
• Ask for dated fork-service records. A clean exterior does not establish the condition of internal seals, oil or bushings.

Archived: Group: Mountain Mix · Shifters: Shimano Deore LX RapidFire SL · Front derailleur: Shimano Deore LX top-swing · Rear derailleur: Shimano Deore XT SGS · Crankset: Shimano Deore LX, 22/32/44 teeth · Bottom bracket: Shimano BB-ES70 · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG72, 1/2 x 3/32"

• Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
• Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
• Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Archived: Brakes: Formula Evoluzione Hydraulic disc front/Koski Brake Lite Pro rear brakes, Formula Evoluzione Hydraulic disc front/Koski #2520 Power Curve rear levers

• Squeeze each lever firmly. It should feel consistent and return cleanly. Check levers, hoses and calipers for fluid, inspect pad thickness and contamination, and examine rotors for wear or bending.

Archived: Wheel size: 26" wheels · Rims: Mavic X221, 32-hole · Hubs: Front: Real Disc, Rear: Shimano Deore XT Disc · Front tire: 26 x 2.10" Tioga Factory XC Extreme

• Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
• Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Archived: Headset: 1 1/8" threadless Tange DX · Handlebar: Syncros 6061 Lo-Riser · Stem: Syncros · Seatpost: Syncros 6061 · Saddle: SDG Grand Prix · Pedals: Ritchey Logic Comp v.2

• Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
• Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
