2024 Giant Glory Advanced
Original specifications: 16.42kg (36lbs 04oz) - Size (S/M) published weight · geometry for 3 published sizes.
Planning to sell? Draft your listing
At a glance
Archive #900002350- Model year
- 2024
- Category
- Mountain
- Original MSRP
- $8,400.00
- Sizes
- S, M, L
- Colors
- Shoreline/Carbon
- Weight
- 16.42kg (36lbs 04oz) - Size (S/M)
- Geometry
- 3 manufacturer sizes
- In this record
- 20 specifications · 8 archived images · original MSRP · geometry
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2024 archived details
- Published colors
- Shoreline/Carbon
- Frame
- Carbon Fiber
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildCarbon Fiber
Frameset
| Frame Construction | Advanced-grade composite front and rear triangles, 200mm Maestro suspension, flip chip - headset, flip chip - dropout DH, flip chip - Maestro 3, 12x157mm thru-axle, 27.5 or 29-inch rear wheel compatible |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Fox 40 Factory, GRIP2 damper, 203mm, 20x110, custom tuned for Giant |
| Rear Shock | Fox DHX2 Factory, SLS coil, 225/75, custom tuned for Giant S #425, M #450, L #475 |
Drivetrain
| Shifters | SRAM GX Eagle DH, 1x7 |
|---|---|
| Rear Derailleur | SRAM GX Eagle DH |
| Crankset | TruVativ Descendent DH, 34t, 56.5mm chainline, S:165mm, M:170mm, L:170mm |
| Bottom Bracket | SRAM DUB, threaded, 83mm |
| Cassette | SRAM GX DH, 11-25 |
| Chain | SRAM PC 1110 |
Brakes
| Brakes | Shimano Saint M-820, hydraulic, Shimano RT-66 rotors, [F]220mm, [R]203mm |
|---|
Cockpit & Contact Points
| Handlebar | Giant Contact SL TR35, composite, 800x35mm, 20mm rise |
|---|---|
| Stem | TruVativ Descendant Direct Mount, 35 S:50mm, M:50mm, L:50mm |
| Saddle | Giant Romero |
| Seatpost | Giant Contact, 30.9mm, 0 offset, 400mm |
Wheels & Tires
| Hubs | [F] alloy, open-race sealed bearing, 6-bolt, 20x110mm [R] alloy, 72t pawl driver, open-race sealed bearing, 6-bolt, 12x157mm |
|---|---|
| Rims | Giant AM30, alloy, 28-hole, 30mm inner width |
| Spokes | Sapim Laser, straight pull, DBL |
| Front Tire | Maxxis Assegai 29x2.5 WT, 3C MaxxGrip, DH, TR |
| Rear Tire | Maxxis Minion DHR II 27.5x2.4 WT, 3C, MaxxGrip, DH, TR tubeless |
No specifications match. Try a component name or clear your search.
Geometry
Frame measurements by size.
Reference drawing
Select an available measurement to locate it on the frame.
All geometry measurements9 size / setup combinations · 17 measurements
| Measurement | S/M · Low | S/M · Mid | S/M · High | M/L · Low | M/L · Mid | M/L · High | L/XL · Low | L/XL · Mid | L/XL · High |
|---|---|---|---|---|---|---|---|---|---|
| Seat tube | 430 mm | 430 mm | 430 mm | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Top tube | 571.2 mm | 570.5 mm | 569.8 mm | 591.3 mm | 590.5 mm | 589.8 mm | 611.3 mm | 610.6 mm | 609.8 mm |
| Head tube | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm | 110 mm |
| Head-tube angle | 61.6° | 61.9° | 62.3° | 61.6° | 62° | 62.3° | 61.7° | 62° | 62.3° |
| Seat-tube angle | 78.4° | 78.7° | 79.1° | 78.4° | 78.8° | 79.1° | 78.5° | 78.8° | 79.1° |
| Chainstay / rear center | 447.9 mm | 446.5 mm | 445 mm | 447.9 mm | 446.5 mm | 445 mm | 447.9 mm | 446.5 mm | 445 mm |
| Wheelbase | 1273 mm | 1271.9 mm | 1270.6 mm | 1293 mm | 1291.8 mm | 1290.6 mm | 1313 mm | 1311.9 mm | 1310.6 mm |
| Bottom-bracket drop | 13.1 mm | 8.1 mm | 3 mm | 13.3 mm | 8.3 mm | 3.1 mm | 13.5 mm | 8.4 mm | 3.2 mm |
| Reach | 440.9 mm | 444.7 mm | 448.6 mm | 461.2 mm | 464.9 mm | 468.6 mm | 481.5 mm | 485.1 mm | 488.6 mm |
| Stack | 634.6 mm | 631.9 mm | 629.1 mm | 634.9 mm | 632.2 mm | 629.2 mm | 635.3 mm | 632.4 mm | 629.3 mm |
| Standover height | 733.7 mm | 738.2 mm | 742.9 mm | 735.2 mm | 740 mm | 744.8 mm | 742.9 mm | 747.6 mm | 752.3 mm |
| Fork offset / rake | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm | 52 mm |
| Trail | 146.4 mm | 143.6 mm | 140.8 mm | 146.2 mm | 143.5 mm | 140.8 mm | 146 mm | 143.3 mm | 140.8 mm |
| Crank length | 165 mm | 165 mm | 165 mm | 165 mm | 165 mm | 165 mm | 165 mm | 165 mm | 165 mm |
| Stem length | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Handlebar width | 800 mm | 800 mm | 800 mm | 800 mm | 800 mm | 800 mm | 800 mm | 800 mm | 800 mm |
| Wheel size | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" | [R] 27.5" / [F] 29" |
Dimensions as recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
