Velopedia Bicycle Archive
2022 Giant Defy Advanced Pro 2 AX
Original manufacturer specifications including 8.32 kg (18 lb 5oz) - Size (XS) published weight, geometry for 6 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2022
- Category
- Road
- Original MSRP
- $4,800.00
- Sizes
- XS, S, M, M/L, L, XL
- Colors
- Black Chrome / Black
- Weight
- 8.32 kg (18 lb 5oz) - Size (XS)
- Geometry
- 6 manufacturer sizes · Geometry context
- Record coverage
- 24 preserved details · 5 archived images · original MSRP · preserved geometry
- Archive ID
- 900002545
Frameset
| Frame Construction | Advanced-Grade Composite, disc |
|---|---|
| Frame Material | Carbon Fiber |
| Fork | Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc |
| Fork Material | Carbon Fiber |
| Rear Shock | N/A |
Drivetrain
| Shifters | SRAM Rival eTap AXS |
|---|---|
| Front Derailleur | SRAM Rival eTap AXS |
| Rear Derailleur | SRAM Rival eTap AXS |
| Crankset | SRAM Rival D1 DUB, 33/46 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm |
| Bottom Bracket | SRAM DUB, press fit |
| Cassette | SRAM Rival, 12-speed, 10x36 |
| Chain | SRAM Rival D1 |
| Pedals | N/A |
Brakes
| Brakes | SRAM Rival eTap AXS hydraulic, SRAM PaceLine rotors [F]160mm, [R]140mm |
|---|
Cockpit & Contact Points
| Handlebar | Giant Contact SL D-Fuse XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm |
|---|---|
| Stem | Giant Contact SL XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:110mm |
| Saddle | Giant Fleet SL |
| Seatpost | Giant D-Fuse SL, composite, 16mm offset |
Wheels & Tires
| Hubs | Giant SLR 2 36 Carbon Disc WheelSystem, 12mm thru-axle |
|---|---|
| Rims | Giant SLR 2 36 Carbon Disc WheelSystem |
| Spokes | Giant SLR 2 36 Carbon Disc WheelSystem |
| Front Tire | Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding |
| Rear Tire | Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | XS | S | M | ML | L | XL |
|---|---|---|---|---|---|---|
| Seat tube | 410 mm | 445 mm | 480 mm | 515 mm | 535 mm | 565 mm |
| Top tube | 515 mm | 530 mm | 545 mm | 560 mm | 575 mm | 595 mm |
| Head tube | 125 mm | 135 mm | 160 mm | 185 mm | 205 mm | 225 mm |
| Head-tube angle | 70.5° | 71.8° | 72.5° | 72.5° | 72.5° | 72.5° |
| Seat-tube angle | 74.5° | 74° | 73.5° | 73° | 73° | 72.5° |
| Chainstay / rear center | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 995 mm | 995 mm | 998 mm | 1010 mm | 1025 mm | 1040 mm |
| Bottom-bracket drop | 75 mm | 75 mm | 75 mm | 70 mm | 70 mm | 70 mm |
| Reach | 370 mm | 374 mm | 377 mm | 381 mm | 390 mm | 398 mm |
| Stack | 522 mm | 546 mm | 567 mm | 586 mm | 605 mm | 624 mm |
| Standover height | 731 mm | 760 mm | 786 mm | 816 mm | 835 mm | 856 mm |
| Fork offset / rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71.3 mm | 63.1 mm | 58.2 mm | 58.2 mm | 58.2 mm | 58 mm |
| Crank length | 170 mm | 170 mm | 172.5 mm | 172.5 mm | 175 mm | 175 mm |
| Stem length | 80 mm | 90 mm | 100 mm | 100 mm | 110 mm | 110 mm |
| Handlebar width | 400 mm | 400 mm | 420 mm | 420 mm | 440 mm | 440 mm |
| Wheel size | 700C | 700C | 700C | 700C | 700C | 700C |
Geometry source: Giant first-party size geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
XS geometry
Archive context: The head angle of 70.5° sits toward the slacker end. Its wheelbase of 995 mm sits toward the longer end. The chainstay of 420 mm sits toward the longer rear-center end.
Compared with 23 distinct road geometries in the XS-equivalent size cohort from model years 2020–2024 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XS geometry S geometry
Archive context: The chainstay of 420 mm sits toward the longer rear-center end. Its reach of 374 mm sits somewhat shorter than typical. Its stack of 546 mm sits somewhat taller than typical.
Compared with 30 distinct road geometries in the Small-equivalent size cohort from model years 2020–2024 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: Its reach of 377 mm sits toward the shorter end. Its bottom-bracket drop of 75 mm sits somewhat deeper than typical. The chainstay of 420 mm sits somewhat longer than typical.
Compared with 33 distinct road geometries in the Medium-equivalent size cohort from model years 2020–2024 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry ML geometry
Archive context: Its stack of 586 mm sits toward the taller end. The seat angle of 73° sits toward the more relaxed end. Its wheelbase of 1010 mm sits toward the longer end.
Compared with 33 distinct road geometries in the Medium-equivalent size cohort from model years 2020–2024 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze ML geometry L geometry
Archive context: Its stack of 605 mm sits toward the taller end. Its wheelbase of 1025 mm sits toward the longer end. The seat angle of 73° sits toward the more relaxed end.
Compared with 25 distinct road geometries in the Large-equivalent size cohort from model years 2020–2024 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry XL geometry
Archive context: Its stack of 624 mm sits toward the taller end. Its wheelbase of 1040 mm sits toward the longer end. The seat angle of 72.5° sits toward the more relaxed end.
Compared with 22 distinct road geometries in the XL-equivalent size cohort from model years 2020–2024 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry Parts & serviceability
Find replacement parts
SRAM Rival D1
Interpreted as SRAM Rival · 12-speed Named component · published drivetrain speed — verify exact version
SRAM Rival, 12-speed, 10x36
Interpreted as SRAM Rival · 12-speed Component family — verify exact version
SRAM DUB, press fit
Named archived component — verify dimensions
More qualified parts (3)
SRAM Rival eTap AXS
Interpreted as SRAM Rival · 12-speed · electronic Component family — verify exact version
SRAM Rival eTap AXS
Interpreted as SRAM Rival · 12-speed · electronic Component family — verify exact version
SRAM Rival eTap AXS
Interpreted as SRAM Rival · 12-speed · electronic Component family — verify exact version
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- DrivetrainConfirm every shift-system battery charges, every shift control works and the derailleur moves cleanly across the cassette. Make sure the matching shift-system charger is included, then measure chain wear and inspect the cassette teeth.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
- Bottom bracketTurn the cranks slowly, feel for rough bearings and check for side-to-side play. Creaking under load deserves investigation but does not identify the source by itself.Inspect the bottom bracket and shell →
Bike-specific inspection checklist 20 checks based on 5 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2022 Giant Defy Advanced Pro 2 AX · Road · Published sizes: XS, S, M, M/L, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: Advanced-Grade Composite, disc · Fork: Advanced-Grade Composite, full-composite OverDrive 2 steerer, disc · Carbon Fiber
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM Rival eTap AXS · Front derailleur: SRAM Rival eTap AXS · Rear derailleur: SRAM Rival eTap AXS · Crankset: SRAM Rival D1 DUB, 33/46 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm · Bottom bracket: SRAM DUB, press fit · Cassette: SRAM Rival, 12-speed, 10x36 · Chain: SRAM Rival D1
Brakes
Inspect the brakes →Archived: Brakes: SRAM Rival eTap AXS hydraulic, SRAM PaceLine rotors [F]160mm, [R]140mm
Wheels and tires
Check wheels and tires →Archived: Rims: Giant SLR 2 36 Carbon Disc WheelSystem · Hubs: Giant SLR 2 36 Carbon Disc WheelSystem, 12mm thru-axle · Front tire: Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding · Rear tire: Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding
Controls and contact points
Archived: Handlebar: Giant Contact SL D-Fuse XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm · Stem: Giant Contact SL XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:110mm · Seatpost: Giant D-Fuse SL, composite, 16mm offset · Saddle: Giant Fleet SL
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
