2020 Giant Reign 2
Original manufacturer specifications including geometry for 4 published sizes.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2020
- Category
- Mountain
- Original MSRP
- $2,700.00
- Sizes
- S, M, L, XL
- Colors
- Teal Gray / Black
- Geometry
- 4 manufacturer sizes · Geometry context
- Record coverage
- 22 preserved details · archived image · original MSRP · preserved geometry
- Archive ID
- 900002567
Model history 8 other years
Frameset
| Frame Construction | ALUXX SL-Grade Aluminum, 160mm |
|---|---|
| Frame Material | Aluminum |
| Fork | RockShox Yari RC DebonAir, 170mm, Boost 15x110 Maxle Stealth, tapered, 46mm offset |
| Rear Shock | RockShox Deluxe Select+ |
Drivetrain
| Shifters | SRAM SX |
|---|---|
| Front Derailleur | N/A |
| Rear Derailleur | SRAM SX |
| Crankset | SRAM SX DUB 30t, with MRP AMg CS guide |
| Bottom Bracket | SRAM DUB, press fit |
| Cassette | SRAM SX, 10x50 |
| Chain | SRAM SX |
| Pedals | N/A |
Brakes
| Brakes | Shimano MT420 |
|---|
Cockpit & Contact Points
| Handlebar | Giant Contact TR35, 800x35mm, 20mm rise |
|---|---|
| Stem | Giant Contact SL 35 |
| Saddle | Giant Contact (neutral) |
| Seatpost | Giant Contact Switch dropper post with remote, 30.9 |
Wheels & Tires
| Hubs | [F] Giant Tracker Performance Boost 15x110, sealed bearing [R] Giant Tracker Performance Boost 12x148, sealed bearing |
|---|---|
| Rims | Giant AM 27.5 tubeless ready sleeve-joint rim, 30mm inner width |
| Spokes | Sapim |
| Front Tire | [F] Maxxis Minion DHF 27.5x2.5 WT, folding, EXO, TR, tubeless, [R] Maxxis Minion DHRII 27.5x2.4 WT, folding, EXO, TR, tubeless |
| Rear Tire | [F] Maxxis Minion DHF 27.5x2.5 WT, folding, EXO, TR, tubeless, [R] Maxxis Minion DHRII 27.5x2.4 WT, folding, EXO, TR, tubeless |
Size-specific frame data
Geometry
Manufacturer-published geometry normalized for consistent archival comparison. Effective top tube and reach remain separate measurements because they describe different aspects of fit.
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Seat tube | 380 mm | 431 mm | 464 mm | 496 mm |
| Top tube | 601 mm | 637 mm | 657 mm | 682 mm |
| Head tube | 95 mm | 95 mm | 115 mm | 125 mm |
| Head-tube angle | 64.5° | 64.5° | 64.5° | 64.5° |
| Seat-tube angle | 72.5° | 72.5° | 72.5° | 72.5° |
| Chainstay / rear center | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1178 mm | 1213 mm | 1236 mm | 1262 mm |
| Bottom-bracket drop | 7 mm | 7 mm | 7 mm | 7 mm |
| Reach | 419 mm | 454 mm | 469 mm | 491 mm |
| Stack | 580 mm | 580 mm | 599 mm | 608 mm |
| Standover height | 697 mm | 716 mm | 741 mm | 761 mm |
| Fork offset / rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 120 mm | 120 mm | 120 mm | 120 mm |
| Crank length | 170 mm | 175 mm | 175 mm | 175 mm |
| Stem length | 40 mm | 50 mm | 50 mm | 60 mm |
| Handlebar width | 800 mm | 800 mm | 800 mm | 800 mm |
| Wheel size | 27.5" | 27.5" | 27.5" | 27.5" |
Geometry source: Giant first-party size geometry table ↗ Measurements can vary by configuration, wheel size, or flip-chip position where noted by the manufacturer.
Geometry tools
Analyze a published size
S geometry
Archive context: Its bottom-bracket drop of 7 mm sits toward the shallower-drop end. The seat angle of 72.5° sits toward the more relaxed end. The head angle of 64.5° sits toward the slacker end.
Compared with 95 distinct mountain geometries in the Small-equivalent size cohort from model years 2018–2022 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze S geometry M geometry
Archive context: Its stack of 580 mm sits toward the lower end. Its bottom-bracket drop of 7 mm sits toward the shallower-drop end. The seat angle of 72.5° sits toward the more relaxed end.
Compared with 99 distinct mountain geometries in the Medium-equivalent size cohort from model years 2018–2022 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze M geometry L geometry
Archive context: Its bottom-bracket drop of 7 mm sits toward the shallower-drop end. Its stack of 599 mm sits toward the lower end. The seat angle of 72.5° sits toward the more relaxed end.
Compared with 94 distinct mountain geometries in the Large-equivalent size cohort from model years 2018–2022 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze L geometry XL geometry
Archive context: Its stack of 608 mm sits toward the lower end. Its bottom-bracket drop of 7 mm sits toward the shallower-drop end. The seat angle of 72.5° sits toward the more relaxed end.
Compared with 85 distinct mountain geometries in the XL-equivalent size cohort from model years 2018–2022 in the Velopedia archive.Want to go deeper?Open this exact published size and configuration in the Velopedia Geometry Analyzer, then complete any measurements the manufacturer did not provide.
Analyze XL geometry Parts & serviceability
Find replacement parts
SRAM DUB, press fit
Named archived component — verify dimensions
SRAM SX DUB 30t, with MRP AMg CS guide
Component family — verify exact version
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameLook closely for dents and hairline cracks around welds, the head tube and bottom-bracket area. Cosmetic scratches matter less than a change in shape or a crack line.Inspect the frame and fork →
- BrakesTest each brake separately and confirm it stops firmly and releases cleanly. Inspect the pads and braking surfaces for wear or contamination, and check the cables or hoses for damage.Inspect the brakes →
- SuspensionAsk when the fork and shock were last serviced. Check the stanchions for damage, look for oil at the seals, cycle both units through their travel and test the suspension pivots for play.Evaluate the suspension →
- DrivetrainShift through the full range under light load, measure chain wear and inspect the cassette or freewheel teeth. Skipping or hesitation can indicate wear, poor adjustment or mismatched parts.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads. If it is set up tubeless, confirm both tires hold pressure and ask when the sealant was last refreshed.Check wheels and tires →
Bike-specific inspection checklist 23 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2020 Giant Reign 2 · Mountain · Published sizes: S, M, L, XL
Frame and fork
Inspect the frame and fork →Archived: Frame: ALUXX SL-Grade Aluminum, 160mm · Fork: RockShox Yari RC DebonAir, 170mm, Boost 15x110 Maxle Stealth, tapered, 46mm offset
Suspension
Evaluate the suspension →Archived: Fork: RockShox Yari RC DebonAir, 170mm, Boost 15x110 Maxle Stealth, tapered, 46mm offset · Rear shock: RockShox Deluxe Select+
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM SX · Rear derailleur: SRAM SX · Crankset: SRAM SX DUB 30t, with MRP AMg CS guide · Bottom bracket: SRAM DUB, press fit · Cassette: SRAM SX, 10x50 · Chain: SRAM SX
Brakes
Inspect the brakes →Archived: Brakes: Shimano MT420
Wheels and tires
Check wheels and tires →Archived: Rims: Giant AM 27.5 tubeless ready sleeve-joint rim, 30mm inner width · Hubs: [F] Giant Tracker Performance Boost 15x110, sealed bearing [R] Giant Tracker Performance Boost 12x148, sealed bearing · Front tire: [F] Maxxis Minion DHF 27.5x2.5 WT, folding, EXO, TR, tubeless, [R] Maxxis Minion DHRII 27.5x2.4 WT, folding, EXO, TR, tubeless · Rear tire: [F] Maxxis Minion DHF 27.5x2.5 WT, folding, EXO, TR, tubeless, [R] Maxxis Minion DHRII 27.5x2.4 WT, folding, EXO, TR, tubeless
Controls and contact points
Archived: Handlebar: Giant Contact TR35, 800x35mm, 20mm rise · Stem: Giant Contact SL 35 · Seatpost: Giant Contact Switch dropper post with remote, 30.9 · Saddle: Giant Contact (neutral)
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
Have you owned this bike?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Current market
Snapshot not yet availableProtected live updateReady after page interactionAutomated crawlers do not trigger marketplace requests.
Move, scroll, tap or type to start the protected update.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
