Velopedia Bicycle Archive
At a glance
Archive #1000085- Model year
- 2012
- Category
- Mountain
- Original MSRP
- $3,150.00
- Sizes
- S, M, L, XL
- Colors
- Black/Silver
- In this record
- 18 specifications · 2 archived images · original MSRP
Model history 2 other years
Browse other years
Compare side by side
Identification clues
2012 archived details
- Published colors
- Black/Silver
- Frame
- ALUXX SL Grade alum/4" travel
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildALUXX SL Grade alum/4" travel
Frameset
| Frame Material | ALUXX SL Grade alum/4" travel |
|---|---|
| Fork | Fox Float RL Evolution 100mm |
| Rear Shock | Fox Float RP2 Boost Valve |
Drivetrain
| Shifters | Shimano Deore XT 10spd |
|---|---|
| Front Derailleur | Shimano Deore XT |
| Rear Derailleur | Shimano Deore XT |
| Crankset | Shimano Deore XT 38/26t |
| Bottom Bracket | Shimano Press Fit |
| Cassette | Shimano HG81 10spd 11-36t |
| Chain | Shimano HG-74 |
| Pedals | not included |
Brakes
| Brakes | Avid Elixir 7 160mm |
|---|
Cockpit & Contact Points
| Handlebar | Giant Connect SL low rise |
|---|---|
| Stem | Giant Contact 31.8mm |
| Saddle | Fizik Tundra 2 Manganese |
| Seatpost | Giant Connect SL 30.9mm |
Wheels & Tires
| Hubs | Giant Tracker 15mm Giant Tracker |
|---|---|
| Front Tire | Schwalbe Racing Ralph 26x2.1 |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
Speed unavailable: wheel or tire size is missing or unclear.
Add your rear tire size to calculate speedHow it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts

Race Face Ride XC Seatpost Black, 30.9x375mm
Replacement option
More parts (6)Fewer parts
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Schwalbe Racing Ralph 26x2.1
- Drivetrain
- 10-speed
- Seatpost diameter
- 30.9 mm
- Bottom bracket / shell
- Shimano Press Fit
Equipment inspection checks 13 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: ALUXX SL Grade alum/4" travel · Fork: Fox Float RL Evolution 100mm
Suspension
Evaluate the suspension →Archived: Fork: Fox Float RL Evolution 100mm · Rear shock: Fox Float RP2 Boost Valve
Drivetrain
Check drivetrain wear →Archived: Shifters: Shimano Deore XT 10spd · Front derailleur: Shimano Deore XT · Rear derailleur: Shimano Deore XT · Crankset: Shimano Deore XT 38/26t · Bottom bracket: Shimano Press Fit · Cassette: Shimano HG81 10spd 11-36t · Chain: Shimano HG-74
Brakes
Inspect the brakes →Archived: Brakes: Avid Elixir 7 160mm
Wheels and tires
Check wheels and tires →Archived: Hubs: Giant Tracker 15mm Giant Tracker · Front tire: Schwalbe Racing Ralph 26x2.1
Controls and contact points
Archived: Handlebar: Giant Connect SL low rise · Stem: Giant Contact 31.8mm · Seatpost: Giant Connect SL 30.9mm · Saddle: Fizik Tundra 2 Manganese · Pedals: not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Gallery2 images
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
