Velopedia Bicycle Archive

2009 Giant Seek 2

Original specifications: SRAM X5 · 9-speed · mechanical rear derailleur · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #16724
Model year
2009
Category
City & Commuter
Original MSRP
$700.00
Sizes
S, M, L, XL
Colors
Smoke Gray
In this record
25 specifications · archived image · original MSRP
Model history 3 other years

Browse other years

Compare side by side

Identification clues

2009 archived details

Published colors
Smoke Gray
Frame
ALUXX aluminum
Original equipment
Commuter Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildALUXX aluminum · Commuter Mix · 700c wheels

Historical catalog variants

Archived sizes and colors

4 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

SMLXL

Published colors

Smoke Gray
View 4 archived size/color combinations
SizeColor
SSmoke Gray
MSmoke Gray
LSmoke Gray
XLSmoke Gray

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame MaterialALUXX aluminum
ForkGiant
Fork MaterialChromoly w/ alloy steerer, unicrown crown

Drivetrain

Component GroupCommuter Mix
ShiftersSRAM X.5 Trigger
Front DerailleurShimano M530
Rear DerailleurSRAM X.5
CranksetFSA Alpha Drive, 26/36/48 teeth
Bottom BracketFSA Powerdrive
CassetteShimano HG50
Rear Cogs9-speed, 11 - 34 teeth
ChainShimano HG50
PedalsAlloy Platform

Brakes

BrakesAvid Juicy 3 brakes, Avid Juicy 3 levers

Cockpit & Contact Points

HandlebarAlloy Riser
Handlebar ExtensionsNot included
StemAlloy
SaddleUnity SuperSoft Venture
SeatpostAlloy, 30.9mm diameter

Wheels & Tires

HubsFormula sealed disc
RimsAlex ACE-18, 36-hole
SpokesStainless
Front Tire700 x 32c Maxxis Columbiere
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes48/36/26T · 11–34T · 9-speed
Lowest0.76:1 Highest4.36:1 Total range571%
Estimated speed At 90 RPM Lowest gear5.5 mph Highest gear31.6 mph

Uses front tire 700C×32; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
700 x 32c Maxxis Columbiere
Chain · Original
Shimano HG50
More parts (6)Fewer parts
Cassette · Original
Shimano HG50
Bottom bracket · Original
FSA Powerdrive
Crankset · Original
FSA Alpha Drive

26/36/48 teeth

Rear derailleur · Original
SRAM X.5
Shifters · Original
SRAM X.5 Trigger
Rims · Original
Alex ACE-18

36-hole

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 32c Maxxis Columbiere
Drivetrain
9-speed
Seatpost diameter
30.9 mm
Bottom bracket / shell
FSA Powerdrive
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Giant · Chromoly w/ alloy steerer, unicrown crown

Archived: Group: Commuter Mix · Shifters: SRAM X.5 Trigger · Front derailleur: Shimano M530 · Rear derailleur: SRAM X.5 · Crankset: FSA Alpha Drive, 26/36/48 teeth · Bottom bracket: FSA Powerdrive · Cassette: Shimano HG50 · Rear cogs: 9-speed, 11 - 34 teeth · Chain: Shimano HG50

Archived: Brakes: Avid Juicy 3 brakes, Avid Juicy 3 levers

Archived: Wheel size: 700c wheels · Rims: Alex ACE-18, 36-hole · Hubs: Formula sealed disc · Front tire: 700 x 32c Maxxis Columbiere

Controls and contact points

Archived: Handlebar: Alloy Riser · Stem: Alloy · Seatpost: Alloy, 30.9mm diameter · Saddle: Unity SuperSoft Venture · Pedals: Alloy Platform
