2008 Giant Aeryn

Original specifications: Shimano 105 drivetrain · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #24143
Model year
2008
Category
Road
Original MSRP
$2,000.00
Sizes
XS, S, M
Colors
White/Gold
In this record
25 specifications · archived image · original MSRP
Model history 1 other year

Browse other years

Compare side by side

Identification clues

2008 archived details

Published colors
White/Gold
Frame
Alliance aluminum/composite
Original equipment
Shimano 105

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildAlliance aluminum/composite · Shimano 105 · 700c wheels

Historical catalog variants

Archived sizes and colors

3 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

XSSM

Published colors

White/Gold
View 3 archived size/color combinations
SizeColor
XSWhite/Gold
SWhite/Gold
MWhite/Gold

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded/bonded
Frame MaterialAlliance aluminum/composite
ForkFormulaOne Aero Composite
Fork MaterialCarbon/alloy steerer, aero crown

Drivetrain

Component GroupShimano 105
ShiftersShimano Dura-Ace Bar-con
Front DerailleurShimano 105
Rear DerailleurShimano Ultegra
CranksetRace Face Cadence, 39/53 teeth
Bottom BracketRace Face Road X-Type
Rear Cogs10-speed, 11 - 23 teeth
ChainShimano 105
PedalsNot included

Brakes

BrakesShimano 105 brakes, Tektro RX 4.1 levers

Cockpit & Contact Points

Headset1 1/8" integrated
HandlebarVision
Handlebar ExtensionsVision straight clip-on
StemVision Size More
SaddleFi'zi:k Vitesse Tri w/k:ium rails
SeatpostFormulaOne Composite, aero diameter

Wheels & Tires

HubsXero XGR-1
RimsXero XGR-1
SpokesXero
Front Tire700 x 23c Michelin ProRace3
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes53/39T · 11–23T · 10-speed
Lowest1.70:1 Highest4.82:1 Total range284%
Estimated speed At 90 RPM Lowest gear11.9 mph Highest gear33.9 mph

Uses front tire 700C×23; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
700 x 23c Michelin ProRace3
Retailer offers
Chain · Original
Shimano 105
Bottom bracket · Original
Race Face Road X-Type
More parts (5)Fewer parts
Saddle · Original
Fi'zi:k Vitesse Tri w/k:ium rails
Crankset · Original
Race Face Cadence

39/53 teeth

Front derailleur · Original
Shimano 105
Rear derailleur · Original
Shimano Ultegra
Shifters · Original
Shimano Dura-Ace Bar-con

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 23c Michelin ProRace3
Drivetrain
10-speed
Bottom bracket / shell
Race Face Road X-Type
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded/bonded · Fork: FormulaOne Aero Composite · Carbon/alloy steerer, aero crown

Archived: Group: Shimano 105 · Shifters: Shimano Dura-Ace Bar-con · Front derailleur: Shimano 105 · Rear derailleur: Shimano Ultegra · Crankset: Race Face Cadence, 39/53 teeth · Bottom bracket: Race Face Road X-Type · Rear cogs: 10-speed, 11 - 23 teeth · Chain: Shimano 105

Archived: Brakes: Shimano 105 brakes, Tektro RX 4.1 levers

Archived: Wheel size: 700c wheels · Rims: Xero XGR-1 · Hubs: Xero XGR-1 · Front tire: 700 x 23c Michelin ProRace3

Controls and contact points

Archived: Headset: 1 1/8" integrated · Handlebar: Vision · Stem: Vision Size More · Seatpost: FormulaOne Composite, aero diameter · Saddle: Fi'zi:k Vitesse Tri w/k:ium rails · Pedals: Not included
