Velopedia Bicycle Archive
2004 Giant TCR Aero 1
Road race & triathlon bicycle from the Velopedia specification archive.
- Original MSRP
- $1,600.00
- Sizes
- Large, medium, small, xlarge, xsmall
- Colors
- Candy Red
- Archive ID
- 31506
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Aluxx SL aluminum |
| Fork | Giant Composite Aero |
| Fork Material | Carbon fiber composite w/aluminum steerer, aero crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Shimano Ultegra |
|---|---|
| Shifters | Shimano Ultegra STI Dual Control |
| Front Derailleur | Shimano Ultegra, braze-on |
| Rear Derailleur | Shimano Ultegra SS |
| Crankset | TruVativ Rouleur, 39/53 teeth |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 12 - 26 teeth |
| Chain | 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Shimano Ultegra Dual Pivot brakes, Shimano Ultegra STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless FSA integrated |
|---|---|
| Handlebar | Easton EA50 |
| Handlebar Extensions | Syntace C-2 Streamliner |
| Stem | Easton EA50 |
| Saddle | Fi'zi:k Chrono |
| Seatpost | Giant Composite Aero, 27.2mm diameter |
Wheels & Tires
| Hubs | Shimano |
|---|---|
| Rims | Shimano WH-R540 |
| Spokes | Shimano |
| Front Tire | 700 x 23c Michelin Axial Pro Race |
| Wheel Size | 700c wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
