Lowest0.65:1
Highest2.91:1
Total range450%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.35; rear size isn’t listed.
Velopedia Bicycle Archive
2007 Fuji Panic 1.0
Original specifications: Shimano Deore · 9-speed · mechanical rear derailleur · 26" wheels · 33.9 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #95464- Model year
- 2007
- Category
- BMX
- Sizes
- 14", 16", 18"
- Colors
- Dead Chrome
- Weight
- 33.9 lb
- In this record
- 25 specifications · archived image
Model history 1 other year
Browse other years
Compare side by side
Identification clues
2007 archived details
- Published colors
- Dead Chrome
- Frame
- Fuji Altair 1 AL
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildFuji Altair 1 AL · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Fuji Altair 1 AL |
| Fork | SR Suntour Duro DRD, 100mm travel |
| Fork Material | Aluminum/steel/magnesium, single crown |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | SRAM Attack Trigger |
| Front Derailleur | Shimano Deore, top-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Deore |
| Crankset | TruVativ Hussefelt, 22/32 teeth |
| Bottom Bracket | TruVativ Howitzer |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Chain | KMC HG-73 |
| Pedals | Wellgo resin |
Brakes
| Brakes | Tektro Aquila Mechanical w/180mm rotor front/Tektro Aquila Mechanical w/160mm rotor rear brakes, Tektro ML-570 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" VP |
|---|---|
| Handlebar | TruVativ LE |
| Handlebar Extensions | Not included |
| Stem | TruVativ Hussefelt |
| Saddle | WTB Pure V Sport |
| Seatpost | Fuji Micro Adjust |
Wheels & Tires
| Hubs | Fuji Sealed Bearing DISC |
|---|---|
| Rims | Alex DM-24, 32-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) |
| Front Tire | 26 x 2.35" Kenda Kolossal DH |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
KMC HG-73
WTB Pure V Sport
More parts (2)Fewer parts
Shimano Deore
Alex DM-24
32-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.35" Kenda Kolossal DH
- Drivetrain
- 9-speed
- Bottom bracket / shell
- TruVativ Howitzer
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: SR Suntour Duro DRD, 100mm travel · Aluminum/steel/magnesium, single crown
Suspension
Evaluate the suspension →Archived: Fork: SR Suntour Duro DRD, 100mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: SRAM Attack Trigger · Front derailleur: Shimano Deore, top-pull/clamp-on 31.8mm · Rear derailleur: Shimano Deore · Crankset: TruVativ Hussefelt, 22/32 teeth · Bottom bracket: TruVativ Howitzer · Rear cogs: 9-speed, 11 - 34 teeth · Chain: KMC HG-73
Brakes
Inspect the brakes →Archived: Brakes: Tektro Aquila Mechanical w/180mm rotor front/Tektro Aquila Mechanical w/160mm rotor rear brakes, Tektro ML-570 levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Alex DM-24, 32-hole · Hubs: Fuji Sealed Bearing DISC · Front tire: 26 x 2.35" Kenda Kolossal DH
Controls and contact points
Archived: Headset: 1 1/8" VP · Handlebar: TruVativ LE · Stem: TruVativ Hussefelt · Seatpost: Fuji Micro Adjust · Saddle: WTB Pure V Sport · Pedals: Wellgo resin
