Lowest0.94:1
Highest4.73:1
Total range504%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×28; rear size isn’t listed.
Velopedia Bicycle Archive
2007 Fuji Absolute LX
Original specifications: Shimano Deore · 9-speed · mechanical rear derailleur · 700c wheels · 24 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #95473- Model year
- 2007
- Category
- Road
- Sizes
- 15", 17", 19", 21", 23"
- Colors
- Polished
- Weight
- 24 lb
- In this record
- 25 specifications · archived image
Original buildFuji Altair 1 AL · Road Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Fuji Altair 1 AL |
| Fork | Fuji FC-990 Carbon |
| Fork Material | Carbon w/Cr-Mo steerer, aero crown |
Drivetrain
| Component Group | Road Mix |
|---|---|
| Shifters | SRAM Attack |
| Front Derailleur | Shimano FD-443, 31.8mm |
| Rear Derailleur | Shimano Deore |
| Crankset | TruVativ ISO Flow 3.0 Road, 30/42/52 teeth |
| Bottom Bracket | Fuji Sealed Square Taper |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | KMC Z9000 |
| Pedals | Wellgo LU-962 |
Brakes
| Brakes | Tektro 926AL Mini-V brakes, Tektro RT 354A front/Tektro RT354A rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated Tange IS-24 |
|---|---|
| Handlebar | Fuji Double Butted AL |
| Handlebar Extensions | Not included |
| Stem | Fuji Adjustable AL |
| Saddle | Fuji Sport Comfort |
| Seatpost | Fuji Micro Adjust Aluminum |
Wheels & Tires
| Hubs | Formula sealed |
|---|---|
| Rims | Alex R-500, 32-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) |
| Front Tire | 700 x 28c Kenda Kontender |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 28c Kenda Kontender
Retailer offers
Vittoria Zaffiro Pro V Clincher Tire Black, 700x28
700x28c
Replacement option
Other replacement options (1)
Specialized SW Mondo 2Bliss Tire Black, 700x28
700x28c
Replacement option
Kenda Kontender on eBaySponsored links
Tektro 926AL Mini-V brakes
Tektro RT 354A front/Tektro RT354A rear levers
More parts (4)Fewer parts
Wellgo LU-962
Shimano Deore
Alex R-500
32-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 28c Kenda Kontender
- Drivetrain
- 9-speed
- Bottom bracket / shell
- Fuji Sealed Square Taper
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fuji FC-990 Carbon · Carbon w/Cr-Mo steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Road Mix · Shifters: SRAM Attack · Front derailleur: Shimano FD-443, 31.8mm · Rear derailleur: Shimano Deore · Crankset: TruVativ ISO Flow 3.0 Road, 30/42/52 teeth · Bottom bracket: Fuji Sealed Square Taper · Rear cogs: 9-speed, 11 - 32 teeth · Chain: KMC Z9000
Brakes
Inspect the brakes →Archived: Brakes: Tektro 926AL Mini-V brakes, Tektro RT 354A front/Tektro RT354A rear levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex R-500, 32-hole · Hubs: Formula sealed · Front tire: 700 x 28c Kenda Kontender
Controls and contact points
Archived: Headset: 1 1/8" integrated Tange IS-24 · Handlebar: Fuji Double Butted AL · Stem: Fuji Adjustable AL · Seatpost: Fuji Micro Adjust Aluminum · Saddle: Fuji Sport Comfort · Pedals: Wellgo LU-962
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
