Lowest0.65:1
Highest4.00:1
Total range618%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×1.9; rear size isn’t listed.
Velopedia Bicycle Archive
2006 Fuji Mt. Fuji SL
Original specifications: SRAM X0 · 9-speed · mechanical rear derailleur · 26" wheels · 21.9 lb published weight.
Planning to sell? Draft your listing
No archive photo is available for this record.
At a glance
Archive #94394- Model year
- 2006
- Category
- Mountain
- Sizes
- 15", 17", 19", 20.5", 22"
- Colors
- Brushed Aluminum
- Weight
- 21.9 lb
- In this record
- 24 specifications
Model history 3 other years
Browse other years
Compare side by side
Identification clues
2006 archived details
- Published colors
- Brushed Aluminum
- Frame
- A-6 Quaternary aluminum
- Original equipment
- Mountain Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildA-6 Quaternary aluminum · Mountain Mix · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | A-6 Quaternary aluminum |
| Fork | Rock Shox Sid Team, 80mm travel |
| Fork Material | Aluminum/magnesium, single crown |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | SRAM X.0 Trigger |
| Front Derailleur | SRAM X-Gen, top-pull/clamp-on 31.8mm |
| Rear Derailleur | SRAM X.0 |
| Crankset | Truvativ Firex Team, 22/32/44 teeth |
| Bottom Bracket | Truvativ GXP |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Chain | Shimano CN-HG73, 1/2 x 3/32" |
| Pedals | Not included |
Brakes
| Brakes | Avid Single Digit SL brakes, Avid Speed Dial SL levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated Ritchey Logic Zero Pro |
|---|---|
| Handlebar | Ritchey WCS |
| Stem | Ritchey WCS V3 |
| Saddle | WTB Rocket V Comp |
| Seatpost | Ritchey WCS |
Wheels & Tires
| Hubs | Formula SL |
|---|---|
| Rims | Front: Ritchey WCS Girder XC, Rear: Ritchey WCS Girder XC OCR |
| Spokes | Stainless steel, 15ga. (1.8mm) straight gauge |
| Front Tire | 26 x 1.90" Ritchey Z-Max Millenium |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
26 x 1.90" Ritchey Z-Max Millenium
Retailer offers
Continental Double Fighter III Tire Black, 26x1.9
Replacement option
WTB Rocket V Comp
More parts (7)Fewer parts
SRAM X.0
SRAM X.0 Trigger
Ritchey WCS
Ritchey WCS V3
Ritchey WCS
1 1/8" integrated Ritchey Logic Zero Pro
Formula SL
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 1.90" Ritchey Z-Max Millenium
- Drivetrain
- 9-speed
- Bottom bracket / shell
- Truvativ GXP
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Rock Shox Sid Team, 80mm travel · Aluminum/magnesium, single crown
Suspension
Evaluate the suspension →Archived: Fork: Rock Shox Sid Team, 80mm travel
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: SRAM X.0 Trigger · Front derailleur: SRAM X-Gen, top-pull/clamp-on 31.8mm · Rear derailleur: SRAM X.0 · Crankset: Truvativ Firex Team, 22/32/44 teeth · Bottom bracket: Truvativ GXP · Rear cogs: 9-speed, 11 - 34 teeth · Chain: Shimano CN-HG73, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Avid Single Digit SL brakes, Avid Speed Dial SL levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Front: Ritchey WCS Girder XC, Rear: Ritchey WCS Girder XC OCR · Hubs: Formula SL · Front tire: 26 x 1.90" Ritchey Z-Max Millenium
Controls and contact points
Archived: Headset: 1 1/8" integrated Ritchey Logic Zero Pro · Handlebar: Ritchey WCS · Stem: Ritchey WCS V3 · Seatpost: Ritchey WCS · Saddle: WTB Rocket V Comp · Pedals: Not included
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
