Lowest1.46:1
Highest3.83:1
Total range262%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Rear tire: 700C×32.
Velopedia Bicycle Archive
2005 Fuji Cross Pro
Original specifications: Shimano Dura-Ace · 9-speed · mechanical rear derailleur · 700c wheels · 21.1 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #93354- Model year
- 2005
- Category
- Gravel & Cyclocross
- Sizes
- 49cm, 52cm, 54cm, 58cm, 61cm
- Colors
- Carib Blue
- Weight
- 21.1 lb
- In this record
- 25 specifications · archived image
Model history 5 other years
Browse other years
Compare side by side
Identification clues
2005 archived details
- Published colors
- Carib Blue
- Frame
- A-6 Quaternary aluminum
- Original equipment
- Cyclocross Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildA-6 Quaternary aluminum · Cyclocross Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | A-6 Quaternary aluminum |
| Fork | Fuji |
| Fork Material | Carbon fiber/aluminum steerer, aero crown |
Drivetrain
| Component Group | Cyclocross Mix |
|---|---|
| Shifters | Shimano 105 STI Dual Control |
| Front Derailleur | Shimano 105, top-pull/clamp-on 31.8mm |
| Rear Derailleur | Shimano Dura-Ace SS |
| Crankset | TruVativ Elita Cross, 38/46 teeth |
| Bottom Bracket | Fsa |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 12 - 26 teeth |
| Chain | Shimano CN-HG73, 1/2 x 3/32" |
Brakes
| Brakes | Avid Shorty 4 brakes, Shimano 105 STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless |
|---|---|
| Handlebar | Ritchey Logic Comp |
| Stem | Ritchey Logic Pro |
| Saddle | Fuji UltraLite Racing |
| Seatpost | Ritchey Logic Pro |
Wheels & Tires
| Hubs | Formula |
|---|---|
| Rims | Alex G-2000 |
| Spokes | Stainless steel |
| Front Tire | 700 x 32c Ritchey Speed Max Cross |
| Rear Tire | 700 x 32c Ritchey SpeedMax Cross |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 32c Ritchey Speed Max Cross
Retailer offers
Goodyear Eagle Tubeless Tire Black, 700x32
700x32c
Replacement option
Other replacement options (1)
Challenge Strada Pro Tubeless Tire Tan, 700x32
700x32c
Replacement option
Shimano Dura-Ace SS
More parts (5)Fewer parts
Shimano 105 STI Dual Control
Ritchey Logic Comp
Ritchey Logic Pro
Ritchey Logic Pro
Alex G-2000
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- Front: 700 x 32c Ritchey Speed Max Cross, Rear: 700 x 32c Ritchey SpeedMax Cross
- Drivetrain
- 9-speed
- Bottom bracket / shell
- FSA · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fuji · Carbon fiber/aluminum steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Cyclocross Mix · Shifters: Shimano 105 STI Dual Control · Front derailleur: Shimano 105, top-pull/clamp-on 31.8mm · Rear derailleur: Shimano Dura-Ace SS · Crankset: TruVativ Elita Cross, 38/46 teeth · Bottom bracket: FSA · Rear cogs: 9-speed, 12 - 26 teeth · Chain: Shimano CN-HG73, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Avid Shorty 4 brakes, Shimano 105 STI Dual Control levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex G-2000 · Hubs: Formula · Front tire: Front: 700 x 32c Ritchey Speed Max Cross, Rear: 700 x 32c Ritchey SpeedMax Cross
Controls and contact points
Archived: Headset: 1 1/8" threadless · Handlebar: Ritchey Logic Comp · Stem: Ritchey Logic Pro · Seatpost: Ritchey Logic Pro · Saddle: Fuji UltraLite Racing
Have you owned this model?Help document firsthand fit, ride and maintenance details that may no longer be available.
This archive record has limited published detail. Share what would help another rider understand how this model fit, rode and held up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
Checking current listings…
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
