Lowest0.94:1
Highest4.73:1
Total range504%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 700C×30; rear size isn’t listed.
Velopedia Bicycle Archive
2003 Fuji Touring
Original specifications: Shimano Deore · 9-speed · mechanical rear derailleur · 700c wheels · 26 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #38421- Model year
- 2003
- Category
- Touring
- Original MSRP
- $839.00
- Sizes
- 43cm, 49cm, 54cm, 58cm, 64cm
- Colors
- Black/Burgundy
- Weight
- 26 lb
- Geometry
- Legacy reference
- In this record
- 26 specifications · archived image · original MSRP · geometry
Model history 13 other years
Browse other years
Compare side by side
Identification clues
2003 archived details
- Published colors
- Black/Burgundy
- Frame
- Elios 2 butted chome-moly
- Original equipment
- Touring Mix
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildElios 2 butted chome-moly · Touring Mix · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Elios 2 butted chome-moly |
| Fork | Fuji Aero Road |
| Fork Material | Chromoly, aero crown |
Drivetrain
| Component Group | Touring Mix |
|---|---|
| Shifters | Shimano Tiagra STI Dual Control |
| Front Derailleur | Shimano Tiagra Triple, bottom-pull/clamp-on 28.6mm |
| Rear Derailleur | Shimano Deore SGS |
| Crankset | Cyclone Forged Road, 30/42/52 teeth |
| Bottom Bracket | Sealed cartridge, 116mm spindle |
| BB Shell Width | 68mm English |
| Rear Cogs | 9-speed, 11 - 32 teeth |
| Chain | Shimano CN-HG73, 1/2 x 3/32" |
| Pedals | Wellgo road w/clips and straps |
Brakes
| Brakes | Aluminum cantilever brakes, Shimano Tiagra STI Dual Control levers |
|---|
Cockpit & Contact Points
| Headset | 1" threadless FSA Roller Bearing |
|---|---|
| Handlebar | Aluminum drop bar |
| Stem | Aluminum |
| Saddle | Fuji Road Sport Anatomical |
| Seatpost | Zoom Superlite, 27.2mm diameter |
Wheels & Tires
| Hubs | Front: aluminum, Q/R, Rear: Ritchey Comp Road |
|---|---|
| Rims | Alex X-2100, 36-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 700 x 30c Ritchey Tom Slick |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 554.2 mm |
| Head-tube angle | 70° |
| Seat-tube angle | 73° |
| Chainstay / rear center | 440 mm |
| Wheelbase | 1052 mm |
| Fork offset / rake | 60 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
700 x 30c Ritchey Tom Slick
Retailer offers
Vittoria Zaffiro Pro V Clincher Tire Black, 700x30
700x30c
Replacement option
Other replacement options (1)
Challenge Strada Bianca Pro Tubeless Tire Tan, 700x30
700x30c
Replacement option
Zoom Superlite
27.2mm diameter
Retailer offers
Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (5)Fewer parts
Wellgo road w/clips and straps
Shimano Deore SGS
Shimano Tiagra STI Dual Control
1" threadless FSA Roller Bearing
Alex X-2100
36-hole
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 30c Ritchey Tom Slick
- Drivetrain
- 9-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- Sealed cartridge, 116mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fuji Aero Road · Chromoly, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Touring Mix · Shifters: Shimano Tiagra STI Dual Control · Front derailleur: Shimano Tiagra Triple, bottom-pull/clamp-on 28.6mm · Rear derailleur: Shimano Deore SGS · Crankset: Cyclone Forged Road, 30/42/52 teeth · Bottom bracket: Sealed cartridge, 116mm spindle · Rear cogs: 9-speed, 11 - 32 teeth · Chain: Shimano CN-HG73, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Aluminum cantilever brakes, Shimano Tiagra STI Dual Control levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Alex X-2100, 36-hole · Hubs: Front: aluminum, Q/R, Rear: Ritchey Comp Road · Front tire: 700 x 30c Ritchey Tom Slick
Controls and contact points
Archived: Headset: 1" threadless FSA Roller Bearing · Handlebar: Aluminum drop bar · Stem: Aluminum · Seatpost: Zoom Superlite, 27.2mm diameter · Saddle: Fuji Road Sport Anatomical · Pedals: Wellgo road w/clips and straps
Have you owned this model?Help preserve its real-world history by sharing your owner experience.
Share the details that would help another rider understand how this model fits, rides and holds up over time. Velopedia reviews every contribution before publication.
Already contributed? Send me a fresh private edit link
For privacy, Velopedia shows the same confirmation whether or not an experience exists.
No recent price sample is available for this bike. Check eBay for matching listings.
Find this bike on eBay
Search eBay US; check the model year, size and installed components. We may earn a commission from purchases.
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
