Lowest1.57:1
Highest3.38:1
Total range215%
Estimated speed At 90 RPM
Lowest gear
Highest gear
Uses front tire 26×2.125; rear size isn’t listed.
Velopedia Bicycle Archive
2003 Fuji Captiva
Original specifications: 26" wheels · 34 lb published weight · legacy reference geometry.
Planning to sell? Draft your listing
At a glance
Archive #38499- Model year
- 2003
- Category
- Cruiser
- Original MSRP
- $229.00
- Sizes
- 19", 22", womens 14", womens 17"
- Colors
- Metallic White/Navy Pearl, Platinum/Magenta, Platinum/Olympic Red, Silver/Black
- Weight
- 34 lb
- Geometry
- Legacy reference
- In this record
- 25 specifications · archived image · original MSRP · geometry
Model history 10 other years
Browse other years
Compare side by side
Identification clues
2003 archived details
- Published colors
- Metallic White/Navy Pearl, Platinum/Magenta, Platinum/Olympic Red, Silver/Black
- Frame
- Hi-tensile steel
- Original equipment
- N/A
Clues, not proof of model year. Colors vary and components may have been replaced.
Original buildHi-tensile steel · 26" wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Hi-tensile steel |
| Fork | Fuji Cruiser |
| Fork Material | Hi-tensile steel, unicrown crown |
Drivetrain
| Shifters | SRAM MRX |
|---|---|
| Rear Derailleur | Shimano Tourney TY-22 |
| Crankset | 1-piece chromoly, 44 teeth |
| Bottom Bracket | Vp |
| BB Shell Width | American |
| Rear Cogs | 7-speed freewheel, 13 - 28 teeth |
| Chain | Shimano CN-UG50, 1/2 x 1/8" |
| Pedals | Wellgo Cruiser |
Brakes
| Brakes | Aluminum linear-pull brakes, aluminum linear-pull levers |
|---|
Cockpit & Contact Points
| Headset | 1" steel |
|---|---|
| Handlebar | Steel, cruiser |
| Handlebar Extensions | Not included |
| Stem | Aluminum 4 bolt |
| Saddle | Fuji Cruiser |
| Seatpost | Aluminum, 25.6mm diameter |
Wheels & Tires
| Hubs | Aluminum, nutted |
|---|---|
| Rims | Aluminum, 36-hole |
| Spokes | Stainless steel, 14ga. (2.0mm) straight gauge |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 2.125" Kenda Cruiser |
| Wheel Size | 26" wheels |
No specifications match. Try a component name or clear your search.
Geometry
Historical measurements. Frame size unknown.
Reference drawing
Size
Measurement
Measurement
—
Select an available measurement to locate it on the frame.
All geometry measurementsLegacy reference · 6 measurements
| Measurement | Legacy reference |
|---|---|
| Top tube | 600 mm |
| Head-tube angle | 68.1° |
| Seat-tube angle | 69° |
| Chainstay / rear center | 520 mm |
| Wheelbase | 1144 mm |
| Fork offset / rake | 38 mm |
Frame size not recorded.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
26 x 2.125" Kenda Cruiser
Retailer offers
Continental Race King Performance Tubeless Tire Black, ShieldWall, 26x2.0
Replacement option
Kenda .125 Cruiser on eBaySponsored links
Aluminum linear-pull brakes
aluminum linear-pull levers
More parts (3)Fewer parts
Wellgo Cruiser
Shimano Tourney TY-22
Aluminum
25.6mm diameter
Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 26 x 2.125" Kenda Cruiser
- Drivetrain
- 7-speed
- Seatpost diameter
- 25.6 mm
- Bottom bracket / shell
- VP · American
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Fuji Cruiser · Hi-tensile steel, unicrown crown
Drivetrain
Check drivetrain wear →Archived: Shifters: SRAM MRX · Rear derailleur: Shimano Tourney TY-22 · Crankset: 1-piece chromoly, 44 teeth · Bottom bracket: VP · Rear cogs: 7-speed freewheel, 13 - 28 teeth · Chain: Shimano CN-UG50, 1/2 x 1/8"
Brakes
Inspect the brakes →Archived: Brakes: Aluminum linear-pull brakes, aluminum linear-pull levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Aluminum, 36-hole · Hubs: Aluminum, nutted · Front tire: 26 x 2.125" Kenda Cruiser
Controls and contact points
Archived: Headset: 1" steel · Handlebar: Steel, cruiser · Stem: Aluminum 4 bolt · Seatpost: Aluminum, 25.6mm diameter · Saddle: Fuji Cruiser · Pedals: Wellgo Cruiser
