Velopedia Bicycle Archive

1994 Fuji Team

Original specifications: Shimano 600 Ultegra STI drivetrain · 21.5 lb published weight · legacy reference geometry.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #17069
Model year
1994
Category
Road
Original MSRP
$1,200.00
Sizes
49, 52, 54, 56, 58, 61, 64
Weight
21.5 lb
Geometry
Legacy reference
In this record
19 specifications · original MSRP · geometry
Model history 15 other years

Browse other years

Compare side by side

Identification clues

1994 archived details

Frame
Ritchey Logic Prestige
Original equipment
Shimano 600 Ultegra STI

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildRitchey Logic Prestige · Shimano 600 Ultegra STI

Manufacturer catalog

Published sizes and colors

7 sizes

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

49525456586164

Frameset

Frame ConstructionTIG-welded steel
Frame MaterialRitchey Logic Prestige
ForkChromoly, Fuji Super-Lite

Drivetrain

Component GroupShimano 600 Ultegra STI
ShiftersShimano 600 Ultegra STI Dual Control
Front DerailleurShimano Ultegra
Rear DerailleurShimano Ultegra
CranksetShimano Ultegra, 42/53 teeth
Rear Cogs8-speed, 12 - 23 teeth
ChainShimano CN-HG90
PedalsShimano PD-6500 600 Ultegra SPD PD-6500 (clipless)

Brakes

BrakesShimano Ultegra "Super SLR" brakes, levers

Cockpit & Contact Points

HandlebarSR, alloy, anatomic
StemFuji TIG-welded chromoly for AheadSet
SaddleFuji Duraflex Superlite Racing
SeatpostSuper-lite 180g

Wheels & Tires

HubsShimano Ultegra, Quick release front & rear
RimsAraya RS-430, 32-hole
Front TireRitchey Road Force

Geometry

Legacy reference · 6 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 6 measurements
MeasurementLegacy reference
Top tube560 mm
Head-tube angle73.5°
Seat-tube angle73°
Chainstay / rear center410 mm
Wheelbase987 mm
Fork offset / rake45 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

All published sizes53/42T · 12–23T · 8-speed
Lowest1.83:1 Highest4.42:1 Total range242%

Speed unavailable: wheel or tire size is missing or unclear.

Add your rear tire size to calculate speed
How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Chain · Original
Shimano CN-HG90
Retailer offers
Pedals · Original
Shimano PD-6500 600 Ultegra SPD PD-6500 (clipless)
Crankset · Original
Shimano Ultegra

42/53 teeth

More parts (4)Fewer parts
Front derailleur · Original
Shimano Ultegra
Rear derailleur · Original
Shimano Ultegra
Shifters · Original
Shimano 600 Ultegra STI Dual Control
Hubs · Original
Shimano Ultegra

Quick release front & rear

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
Ritchey Road Force
Drivetrain
8-speed
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded steel · Fork: Chromoly, Fuji Super-Lite

Archived: Group: Shimano 600 Ultegra STI · Shifters: Shimano 600 Ultegra STI Dual Control · Front derailleur: Shimano Ultegra · Rear derailleur: Shimano Ultegra · Crankset: Shimano Ultegra, 42/53 teeth · Rear cogs: 8-speed, 12 - 23 teeth · Chain: Shimano CN-HG90

Archived: Brakes: Shimano Ultegra "Super SLR" brakes, levers

Archived: Rims: Araya RS-430, 32-hole · Hubs: Shimano Ultegra, Quick release front & rear · Front tire: Ritchey Road Force

Controls and contact points

Archived: Handlebar: SR, alloy, anatomic · Stem: Fuji TIG-welded chromoly for AheadSet · Seatpost: Super-lite 180g · Saddle: Fuji Duraflex Superlite Racing · Pedals: Shimano PD-6500 600 Ultegra SPD PD-6500 (clipless)
