2009 Free Agent Lil Homie

Original specifications: BMX drivetrain · 16" wheels.

Share owner experience

No archive photo is available for this record.

At a glance

Archive #19036

Model year: 2009
Category: BMX
Colors: Infinite Black
In this record: 23 specifications

Model history 1 other year

Browse other years

Compare side by side

Identification clues

2009 archived details

Published colors: Infinite Black
Frame: Chromoly main triangle
Original equipment: BMX

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildChromoly main triangle · BMX · 16" wheels

Historical catalog variants

Archived sizes and colors

1 item record

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published colors

Infinite Black

View 1 archived size/color combination

Size	Color
—	Infinite Black

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame Construction	TIG-welded
Frame Material	Chromoly main triangle
Fork	Free Agent
Fork Material	Hi-tensile steel/chromoly steerer, unicrown crown

Drivetrain

Component Group	BMX
Crankset	Free Agent 3-pc Chromoly, 36 teeth
Bottom Bracket	Euro cartridge
Cassette	Freewheel
Rear Cogs	1-speed, 16 teeth
Chain	KMC Z410, 1/2 x 1/8"
Pedals	VP-505 platform

Brakes

Brakes	Tektro FX-11D U-brake rear brakes, Free Agent Alloy rear levers

Cockpit & Contact Points

Headset	1 1/8" Cane Creek A-head Zero Stack
Handlebar	Free Agent
Handlebar Extensions	Not included
Stem	Free Agent Alloy
Saddle	Free Agent Jump Mini
Seatpost	Steel, 25.4mm diameter

Wheels & Tires

Hubs	Front: Free Agent alloy 3/8", Rear: Free Agent Alloy Cassette 14mm
Rims	Weinmann alloy, 36-hole
Spokes	UCP, 14ga. (2.0mm)
Front Tire	16 x 2.125" Free Agent
Wheel Size	16" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

Published build36T · 16T · 1-speed

Ratio2.25:1

Estimated speed At 90 RPM Gear9.8 mph

Uses front tire 16×2.125; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

16 x 2.125" Free Agent Replacement search: 16x2.125 bicycle tire Before ordering: Check rim type and tire clearance.

Search Amazon Search eBay

Seatpost · Original

Steel

25.4mm diameter

Search Amazon Search eBay

Headset · Original

1 1/8" Cane Creek A-head Zero Stack

Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 16 x 2.125" Free Agent
Drivetrain: 1-speed
Seatpost diameter: 25.4 mm
Bottom bracket / shell: Euro cartridge
