2011 Felt B10

Original specifications: Shimano Dura-Ace drivetrain · 700c wheels · 18.72 lbs published weight.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #23069
Model year
2011
Category
Road
Original MSRP
$5,299.00
Sizes
52, 54, 56, 58, 60cm
Colors
Gloss clear, DuPont red
Weight
18.72 lbs
In this record
26 specifications · archived image · original MSRP
Campaign
Original buildFelt Aero UHC Performance MMC · Shimano Dura-Ace · 700c wheels

Historical catalog variants

Archived sizes and colors

10 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

5254565860cm

Published colors

Gloss ClearDuPont red
View 10 archived size/color combinations
SizeColor
52Gloss Clear
54Gloss Clear
56Gloss Clear
58Gloss Clear
60cmGloss Clear
52DuPont red
54DuPont red
56DuPont red
58DuPont red
60cmDuPont red

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionCarbon
Frame MaterialFelt Aero UHC Performance MMC
ForkFelt Aero UHC Performance
Fork MaterialCarbon

Drivetrain

Component GroupShimano Dura-Ace
ShiftersShimano Dura Ace
Front DerailleurShimano Dura-Ace Di2, braze-on
Rear DerailleurShimano Dura-Ace Di2
CranksetVision TriMax Aluminum, 52/38t teeth
Bottom BracketFSA Mega EXO
CassetteShimano
Rear Cogs10-speed, 12 - 25 teeth
ChainShimano 10 Speed

Brakes

BrakesFelt TTR Aero U-Brake front/TPR Custom SuperLight U-Brake rear brakes, Shimano Dura-Ace levers

Cockpit & Contact Points

HeadsetFSA 1 Integrated
HandlebarFelt 3:1 Bayonet 7005 Superlight
Handlebar ExtensionsNot included
StemFelt SL 6061 Aluminum
SaddleFelt SL
SeatpostFelt Aero UHC Advanced

Wheels & Tires

HubsFELT TTR-3 Sealed
RimsFELT TTR-3, 20-hole/24-hole
SpokesAlpina stainless
Spoke NipplesAluminum nipples
Front Tire700 x 23c Vittoria Zaffiro Pro
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes52/38T · 12–25T · 10-speed
Lowest1.52:1 Highest4.33:1 Total range285%
Estimated speed At 90 RPM Lowest gear10.7 mph Highest gear30.5 mph

Uses front tire 700C×23; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
700 x 23c Vittoria Zaffiro Pro
Retailer offers
Bottom bracket · Original
FSA Mega EXO
Front derailleur · Original
Shimano Dura-Ace Di2

braze-on

More parts (2)Fewer parts
Rear derailleur · Original
Shimano Dura-Ace Di2
Shifters · Original
Shimano Dura Ace

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 23c Vittoria Zaffiro Pro
Drivetrain
10-speed
Bottom bracket / shell
FSA Mega EXO
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: Carbon · Fork: Felt Aero UHC Performance · Carbon

Archived: Group: Shimano Dura-Ace · Shifters: Shimano Dura Ace · Front derailleur: Shimano Dura-Ace Di2, braze-on · Rear derailleur: Shimano Dura-Ace Di2 · Crankset: Vision TriMax Aluminum, 52/38t teeth · Bottom bracket: FSA Mega EXO · Cassette: Shimano · Rear cogs: 10-speed, 12 - 25 teeth · Chain: Shimano 10 Speed

Archived: Brakes: Felt TTR Aero U-Brake front/TPR Custom SuperLight U-Brake rear brakes, Shimano Dura-Ace levers

Archived: Wheel size: 700c wheels · Rims: FELT TTR-3, 20-hole/24-hole · Hubs: FELT TTR-3 Sealed · Front tire: 700 x 23c Vittoria Zaffiro Pro

Controls and contact points

Archived: Headset: FSA 1 Integrated · Handlebar: Felt 3:1 Bayonet 7005 Superlight · Stem: Felt SL 6061 Aluminum · Seatpost: Felt Aero UHC Advanced · Saddle: Felt SL
