Uses front tire 700C×34; rear size isn’t listed.
Velopedia Bicycle Archive
2009 Felt F35X
Original specifications: Shimano 105 drivetrain · 700c wheels · 20.78 lb published weight.
Planning to sell? Draft your listing
At a glance
Archive #18525- Model year
- 2009
- Category
- Gravel & Cyclocross
- Original MSRP
- $1,599.00
- Sizes
- 49cm, 51cm, 53cm, 55cm, 57cm, 59cm
- Colors
- Charcoal Black
- Weight
- 20.78 lb
- In this record
- 26 specifications · archived image · original MSRP
Original buildFELT Custom Butted 7005 Aluminum · Shimano 105 · 700c wheels
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | FELT Custom Butted 7005 Aluminum |
| Fork | Felt CXR |
| Fork Material | Carbon fiber/aluminum steerer, aero crown |
Drivetrain
| Component Group | Shimano 105 |
|---|---|
| Shifters | Shimano 105 STI |
| Front Derailleur | Shimano 105 |
| Rear Derailleur | Shimano 105 |
| Crankset | FSA Gossamer Pro Compact MegaExo, 34/50 teeth |
| Bottom Bracket | FSA Mega EXO |
| Cassette | Shimano |
| Rear Cogs | 10-speed, 11 - 25 teeth |
| Chain | Shimano |
Brakes
| Brakes | Tektro Alloy Canti brakes, Shimano 105 STI w/Tektro top mount levers levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" Cane Creek |
|---|---|
| Handlebar | FELT 1.5 6061 ALU, ergo bend |
| Handlebar Extensions | Not included |
| Stem | FELT 1.2 6061 Aluminum 3D Forged |
| Saddle | FELT 2.2 Anatomic Road Saddle |
| Seatpost | Felt CX.3 6061 ALU, 27.2mm diameter |
Wheels & Tires
| Hubs | Felt aluminum sealed |
|---|---|
| Rims | Mavic CXP 22S, 32-hole |
| Spokes | DT Swiss Champion stainless, 14ga. (2.0mm) |
| Spoke Nipples | Alloy |
| Front Tire | 700 x 34c Vittoria Cross XG Pro |
| Wheel Size | 700c wheels |
No specifications match. Try a component name or clear your search.
Gearing
Lower gears help on climbs. Higher gears suit higher speeds.
RPM = pedal turns per minute.
How it works
Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.
Speeds are estimates from tire size and pedal cadence. Actual speeds vary.
Try your current gearingChanged tires or gears? Calculate your setup.
Your changes apply to this calculation. The archived build stays unchanged.
Gearing results
| Measure | Original | Your setup |
|---|---|---|
| Lowest ratio | — | — |
| Highest ratio | — | — |
| Total range | — | — |
| Lowest-gear speed | — | — |
| Highest-gear speed | — | — |
Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.
Parts & serviceability
Find replacement parts
Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Vittoria Corsa Pro Control G2.0 Tubeless Tire Gumwall/Black, 700x34
700x34c
Replacement option
27.2mm diameter

Race Face Ride XC Seatpost Black, 27.2x375mm
Replacement option
More parts (5)Fewer parts
34/50 teeth
32-hole
Based on the original build. Check fit and installed parts before ordering.
Parts and service referenceQuick reference before buying parts
Archived specifications for reference. Check the fitted parts before ordering.
- Front tire
- 700 x 34c Vittoria Cross XG Pro
- Drivetrain
- 10-speed
- Seatpost diameter
- 27.2 mm
- Bottom bracket / shell
- FSA Mega EXO
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.
Full used-bike inspection guide →
Frame and fork
Inspect the frame and fork →Archived: Frame: TIG-welded · Fork: Felt CXR · Carbon fiber/aluminum steerer, aero crown
Drivetrain
Check drivetrain wear →Archived: Group: Shimano 105 · Shifters: Shimano 105 STI · Front derailleur: Shimano 105 · Rear derailleur: Shimano 105 · Crankset: FSA Gossamer Pro Compact MegaExo, 34/50 teeth · Bottom bracket: FSA Mega EXO · Cassette: Shimano · Rear cogs: 10-speed, 11 - 25 teeth · Chain: Shimano
Brakes
Inspect the brakes →Archived: Brakes: Tektro Alloy Canti brakes, Shimano 105 STI w/Tektro top mount levers levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 700c wheels · Rims: Mavic CXP 22S, 32-hole · Hubs: Felt aluminum sealed · Front tire: 700 x 34c Vittoria Cross XG Pro
Controls and contact points
Archived: Headset: 1 1/8" Cane Creek · Handlebar: FELT 1.5 6061 ALU, ergo bend · Stem: FELT 1.2 6061 Aluminum 3D Forged · Seatpost: Felt CX.3 6061 ALU, 27.2mm diameter · Saddle: FELT 2.2 Anatomic Road Saddle
