2003 EPX Hammerhead Pro
Original manufacturer specifications including Mountain Mix drivetrain, 26" wheels, geometry for 1 published size.
Selling this bike? Create a shareable bike record
What Velopedia knows
- Model year
- 2003
- Category
- Mountain
- Original MSRP
- $4,080.00
- Sizes
- 15.5", 18.5"
- Colors
- Yellow/Red
- Geometry
- Legacy reference · Geometry context
- Record coverage
- 31 preserved details · original MSRP · preserved geometry
- Archive ID
- 30274
Image not available
Frameset
| Frame Construction | Bonded/monocoque |
|---|---|
| Frame Material | Carbon fiber composite |
| Fork | Rock Shox Sid SL |
| Fork Material | Aluminum/magnesium, single crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Mountain Mix |
|---|---|
| Shifters | Shimano Deore XT RapidFire STI |
| Front Derailleur | Shimano Deore XT |
| Rear Derailleur | Shimano XTR |
| Crankset | Shimano Deore XT |
| Bottom Bracket | Shimano BB-ES70 |
| Rear Cogs | 9-speed, 13 - 32 teeth |
| Chain | Shimano CN-HG73, 1/2 x 3/32" |
| Pedals | Crank Brothers Eggbeater |
Brakes
| Brakes | Shimano XTR V-Brake brakes, Shimano Deore XT RapidFire STI levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" integrated |
|---|---|
| Handlebar | EPXtras Carbon |
| Handlebar Extensions | Not included |
| Stem | EPXtras Carbon |
| Saddle | Selle Italia SLR |
| Seatpost | EPXtras Carbon, 27.2mm diameter |
Wheels & Tires
| Hubs | Mavic Crossmax UST |
|---|---|
| Rims | Mavic Crossmax UST, 18-hole/24-hole |
| Spokes | Mavic Zicral, aero |
| Spoke Nipples | Brass nipples |
| Front Tire | 26 x 1.95" Michelin Jet S |
| Wheel Size | 26" wheels |
Historical reference geometry
Geometry
Historical model-level geometry recovered from Velopedia’s original archive database. The source does not identify which listed frame size this reference describes, so fit interpretation is intentionally limited and no size-normalized Archive Context is generated.
| Measurement | Legacy reference |
|---|---|
| Top tube | 560 mm |
| Head-tube angle | 71° |
| Seat-tube angle | 73.5° |
| Chainstay / rear center | 419 mm |
| Wheelbase | 1062 mm |
| Fork offset / rake | 38.1 mm |
Geometry source: Historical archive database — model-level reference geometry. The historical source provides one model-level geometry set and does not identify the corresponding frame size.
Geometry tools
Explore this historical geometry
Model-level historical reference
Period context: At 71°, the head angle sits somewhat steeper than typical among mountain geometries represented in Velopedia for this period. Its 73.5° seat angle is somewhat steeper than typical among the same-period mountain references.
Compared with 529 distinct legacy mountain geometries from model years 2001–2005. Only angular measurements are used because the historical reference frame size is unidentified.See it in periodOpen an immediate comparison with preserved 2003 mountain geometries. The source frame size remains unidentified.
See its 2003 geometry context Parts & serviceability
Find replacement parts
Shimano CN-HG73, 1/2 x 3/32"
Exact archived model
Linear-pull brake pads
Published brake type — verify pad mounting style
Shimano BB-ES70
Exact archived model
More qualified parts (6)
Selle Italia SLR
Named archived component — verify exact version
Shimano Deore XT
Named archived component — verify exact version
Shimano Deore XT
Interpreted as Shimano Deore XT · 9-speed · mechanical Named component · published drivetrain speed — verify exact version
Shimano XTR
Interpreted as Shimano XTR · 9-speed · mechanical Named component · published drivetrain speed — verify exact version
Shimano Deore XT RapidFire STI
Interpreted as Shimano Deore XT · 9-speed · mechanical Named component · published drivetrain speed — verify exact version
27.2 mm seatpost
Published diameter — verify length and setback
Searches use the archived manufacturer specification, not the components currently installed on a particular bicycle. Confirm the exact model, size and fit before ordering. As an Amazon Associate I earn from qualifying purchases. Velopedia may also earn from qualifying eBay purchases. Velopedia may also earn from qualifying retailer purchases. Commercial relationships do not influence Archive specifications or analysis.
Used-bike inspection
If you’re buying this bike used
Before any test ride: both brakes should stop the bike firmly and release cleanly; both wheels should run true and be securely attached; tires should have no casing damage; and the headset, handlebar, stem, cranks and pedals should have no looseness or play.
Follow the full used-bike inspection order →- FrameInspect the frame in bright light, especially around the head tube, bottom bracket, chainstays and clamped areas. Look for cracks, ripples, crushed sections or signs of a previous impact.Inspect the frame and fork →
- BrakesInspect pad condition, cable movement and the rim sidewalls or brake tracks for wear. A concave or heavily worn braking surface can mean the wheel also needs replacement.Inspect the brakes →
- SuspensionAsk when the fork was last serviced. Check the stanchions for damage, look for oil at the seals and make sure the fork moves smoothly without bushing play.Evaluate the suspension →
- DrivetrainShift through every gear under light load and measure chain wear. Confirm that the shifter, derailleur, chain and cassette belong to the same 9-speed system.Check drivetrain wear →
- Wheels & tiresSpin both wheels and watch the rims for side-to-side or vertical movement. Check for dents, cracks, loose or uneven spokes and hub play, then inspect both tire casings for cuts, cracking or exposed threads.Check wheels and tires →
Bike-specific inspection checklist 20 checks based on 6 archived component groups Open checklistClose checklist
This checklist uses the archived equipment for this bike. It cannot confirm the condition, service history or later component changes of the example in front of you.
Identity and fit
Follow the full used-bike inspection order →Archived: 2003 EPX Hammerhead Pro · Mountain bike, front suspension · Published sizes: 15.5", 18.5"
Frame and fork
Inspect the frame and fork →Archived: Frame: Bonded/monocoque · Fork: Rock Shox Sid SL · Aluminum/magnesium, single crown
Suspension
Evaluate the suspension →Archived: Fork: Rock Shox Sid SL
Drivetrain
Check drivetrain wear →Archived: Group: Mountain Mix · Shifters: Shimano Deore XT RapidFire STI · Front derailleur: Shimano Deore XT · Rear derailleur: Shimano XTR · Crankset: Shimano Deore XT · Bottom bracket: Shimano BB-ES70 · Rear cogs: 9-speed, 13 - 32 teeth · Chain: Shimano CN-HG73, 1/2 x 3/32"
Brakes
Inspect the brakes →Archived: Brakes: Shimano XTR V-Brake brakes, Shimano Deore XT RapidFire STI levers
Wheels and tires
Check wheels and tires →Archived: Wheel size: 26" wheels · Rims: Mavic Crossmax UST, 18-hole/24-hole · Hubs: Mavic Crossmax UST · Front tire: 26 x 1.95" Michelin Jet S
Controls and contact points
Archived: Headset: 1 1/8" integrated · Handlebar: EPXtras Carbon · Stem: EPXtras Carbon · Seatpost: EPXtras Carbon, 27.2mm diameter · Saddle: Selle Italia SLR · Pedals: Crank Brothers Eggbeater
Before and during the test ride
Follow the full used-bike inspection order →Build relationships are limited to the archived manufacturer specifications. Confirm exact fit and standards before ordering parts or performing service.
