2010 Electra Townie Sport 105

Original specifications: Shimano 105 · 10-speed rear derailleur · 700c wheels.

Share owner experience

No archive photo is available for this record.

At a glance

Archive #20882

Model year: 2010
Category: City & Commuter
Sizes: One size fits all
Colors: White, Polished Aluminum
In this record: 26 specifications

Model history 2 other years

Browse other years

Compare side by side

Identification clues

2010 archived details

Published colors: White, Polished Aluminum
Frame: 6061-T6 alloy
Original equipment: Commuter Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original build6061-T6 alloy · Commuter Mix · 700c wheels

Historical catalog variants

Archived sizes and colors

2 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

one size fits all

Published colors

WhitePolished Aluminum

View 2 archived size/color combinations

Size	Color
one size fits all	White
one size fits all	Polished Aluminum

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame Construction	TIG-welded
Frame Material	6061-T6 alloy
Fork Material	7075 Alloy w/ alloy steerer, unicrown crown

Drivetrain

Component Group	Commuter Mix
Shifters	Shimano SL-R770 Rapidfire Plus
Front Derailleur	Shimano R770, clamp on
Rear Derailleur	Shimano 105 SS
Crankset	FSA Omega Compact, 34/50 teeth
Bottom Bracket	FSA Omega MegaExo
Cassette	Shimano CS-5600
Rear Cogs	10-speed, 12 - 27 teeth
Chain	Shimano CN-5600
Pedals	Alloy Body & Platform w/ SPD Clipless

Brakes

Brakes	Tektro forged alloy dual pivot brakes, Shimano R770 forged reach adjustable levers

Cockpit & Contact Points

Headset	1 1/8" integrated Alloy threadless
Handlebar	Alloy custom bend, 24.8" x 4.5"
Handlebar Extensions	Not included
Stem	3D Forged Alloy
Saddle	Selle Royal Ariel Vacuum Light
Seatpost	Alloy micro-adjust, 27.2mm diameter

Wheels & Tires

Hubs	Alloy low flange
Rims	Painted Aero Double Wall Alloy, 32-hole
Spokes	Stainless, 14ga. (2.0mm)
Spoke Nipples	Brass
Front Tire	700 x 28c Maxxis Detonator
Wheel Size	700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

Pedal cadence

RPM

Speed units

RPM = pedal turns per minute.

All published sizes50/34T · 12–27T · 10-speed

Lowest1.26:1 Highest4.17:1 Total range331%

Estimated speed At 90 RPM Lowest gear9.0 mph Highest gear29.8 mph

Uses front tire 700C×28; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Gears Drivetrain

Front teeth Smallest rear teeth Largest rear teeth

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Rear tire marking

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

Rim diameter (BSD, mm) Tire width (mm)

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Cadence (RPM) Speed units

Gear, dimension and cadence changes update results automatically.

Gearing comparison
Measure	Original	Your setup
Lowest ratio	—	—
Highest ratio	—	—
Total range	—	—
Lowest-gear speed	—	—
Highest-gear speed	—	—

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Front tire · Original

700 x 28c Maxxis Detonator

Search Amazon Search eBay

Retailer offers

Vittoria Zaffiro Pro V Clincher Tire Black, 700x28

700x28c

Replacement option

Competitive Cyclist ↗$31.21

Other replacement options (1)

Specialized SW Mondo 2Bliss Tire Black, 700x28

700x28c

Replacement option

Backcountry ↗$67.45

Seatpost · Original

Alloy micro-adjust

27.2mm diameter

Search Amazon Search eBay

Retailer offers

Race Face Ride XC Seatpost Black, 27.2x375mm

Replacement option

Competitive Cyclist ↗$38.99

Backcountry ↗$38.99

Chain · Original

Shimano CN-5600

Search Amazon Search eBay

More parts (6)Fewer parts

Cassette · Original

Shimano CS-5600

Search Amazon Search eBay

Bottom bracket · Original

FSA Omega MegaExo

Search Amazon Search eBay

Saddle · Original

Selle Royal Ariel Vacuum Light

Search eBay

Crankset · Original

FSA Omega Compact

34/50 teeth

Search eBay

Rear derailleur · Original

Shimano 105 SS Before ordering: Confirm whether the drivetrain is mechanical or electronic before ordering.

Search eBay

Shifters · Original

Shimano SL-R770 Rapidfire Plus

Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire: 700 x 28c Maxxis Detonator
Drivetrain: 10-speed
Seatpost diameter: 27.2 mm
Bottom bracket / shell: FSA Omega MegaExo

Equipment inspection checks 9 checks based on 5 archived component groups Open equipment checksClose equipment checks

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: · 7075 Alloy w/ alloy steerer, unicrown crown

Look for dents or shape changes and inspect the edges of welds around the head tube, bottom bracket, seat cluster and suspension mounts for hairline cracks.

Drivetrain

Check drivetrain wear →

Archived: Group: Commuter Mix · Shifters: Shimano SL-R770 Rapidfire Plus · Front derailleur: Shimano R770, clamp on · Rear derailleur: Shimano 105 SS · Crankset: FSA Omega Compact, 34/50 teeth · Bottom bracket: FSA Omega MegaExo · Cassette: Shimano CS-5600 · Rear cogs: 10-speed, 12 - 27 teeth · Chain: Shimano CN-5600

Shift through every available gear under light load. Hesitation, skipping or inconsistent indexing can reflect wear, damage, poor adjustment or mismatched replacement parts.
Measure chain wear with a compatible gauge and inspect chainring, cassette or freewheel teeth. A new chain does not rule out wear in the remaining drivetrain.
Turn the cranks slowly, feel for rough bearings and check for side-to-side play. Inspect crank arms, chainring bolts and pedal threads for looseness or damage.

Brakes

Inspect the brakes →

Archived: Brakes: Tektro forged alloy dual pivot brakes, Shimano R770 forged reach adjustable levers

Inspect pads and braking surfaces, check the complete cable or hose path, and confirm both controls feel consistent and return cleanly.

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 700c wheels · Rims: Painted Aero Double Wall Alloy, 32-hole · Hubs: Alloy low flange · Front tire: 700 x 28c Maxxis Detonator

Spin both wheels and watch for side-to-side and vertical movement. Check spoke tension, rim condition and hub play.
Inspect both tire casings for cuts, cracking, plugs, bulges or exposed threads and confirm the installed sizes are safe for the rims and available frame and fork clearance.

Controls and contact points

Archived: Headset: 1 1/8" integrated Alloy threadless · Handlebar: Alloy custom bend, 24.8" x 4.5" · Stem: 3D Forged Alloy · Seatpost: Alloy micro-adjust, 27.2mm diameter · Saddle: Selle Royal Ariel Vacuum Light · Pedals: Alloy Body & Platform w/ SPD Clipless

Apply the front brake and rock the bike to check for headset play or notchiness. Inspect the stem, handlebar and clamp zones, then confirm every fastener and control is secure.
Check that the seatpost moves for adjustment and that the saddle, post and clamp hold securely without cracks, severe corrosion or damaged hardware.
