2010 Diamondback Wildwood

Original specifications: Comfort Mix drivetrain · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #21613
Model year
2010
Category
City & Commuter
Sizes
S (15"), M (17"), LG (19"), XL (21")
Colors
Matte Bronze, Matte Charcoal
In this record
25 specifications
Model history 15 other years

Browse other years

Compare side by side

Identification clues

2010 archived details

Published colors
Matte Bronze, Matte Charcoal
Frame
6061-T6 Heat-Treated Aluminum
Original equipment
Comfort Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build6061-T6 Heat-Treated Aluminum · Comfort Mix · 26" wheels

Historical catalog variants

Archived sizes and colors

8 item records

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

S (15")M (17")LG (19")XL (21")

Published colors

Matte BronzeMatte Charcoal
View 8 archived size/color combinations
SizeColor
S (15")Matte Bronze
M (17")Matte Bronze
LG (19")Matte Bronze
XL (21")Matte Bronze
S (15")Matte Charcoal
M (17")Matte Charcoal
LG (19")Matte Charcoal
XL (21")Matte Charcoal

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material6061-T6 Heat-Treated Aluminum
ForkComfort Suspension, 50mm travel
Fork MaterialSingle

Drivetrain

Component GroupComfort Mix
ShiftersShimano RS35 light action Twist
Front DerailleurMicroShift M20
Rear DerailleurShimano TX-31
CranksetComfort Compact Alloy w/ chainguard, 22/32/42 teeth
Bottom BracketCartridge
CassetteShimano MegaRange
Rear Cogs7-speed, 14 - 34 teeth
PedalsAvenir Comfort Platform

Brakes

BrakesProMax linear-pull brakes, Promax linear levers

Cockpit & Contact Points

Headset1 1/8" Threaded
HandlebarCustom LBC Riser
Handlebar ExtensionsNot included
StemAlloy Adjustable
SaddleAvenir Comfort
SeatpostAlloy Suspension, 27.2mm diameter

Wheels & Tires

HubsAlloy
RimsSSW26 alloy, 32-hole
SpokesStainless, 14ga. (2.0mm)
Front Tire26 x 1.95" Kenda Comfort w/ K-shield
Wheel Size26" wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build42/32/22T · 14–34T · 7-speed
Lowest0.65:1 Highest3.00:1 Total range464%
Estimated speed At 90 RPM Lowest gear4.5 mph Highest gear20.8 mph

Uses front tire 26×1.95; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Seatpost · Original
Alloy Suspension

27.2mm diameter

Search Amazon Search eBay
Retailer offers
Front tire · Original
26 x 1.95" Kenda Comfort w/ K-shield
Search Amazon Search eBay
Brake pads · Original
ProMax linear-pull brakes

Promax linear levers

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 1.95" Kenda Comfort w/ K-shield
Drivetrain
7-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Cartridge
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: Comfort Suspension, 50mm travel · Single

Suspension

Evaluate the suspension →

Archived: Fork: Comfort Suspension, 50mm travel

Drivetrain

Check drivetrain wear →

Archived: Group: Comfort Mix · Shifters: Shimano RS35 light action Twist · Front derailleur: MicroShift M20 · Rear derailleur: Shimano TX-31 · Crankset: Comfort Compact Alloy w/ chainguard, 22/32/42 teeth · Bottom bracket: Cartridge · Cassette: Shimano MegaRange · Rear cogs: 7-speed, 14 - 34 teeth

Brakes

Inspect the brakes →

Archived: Brakes: ProMax linear-pull brakes, Promax linear levers

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 26" wheels · Rims: SSW26 alloy, 32-hole · Hubs: Alloy · Front tire: 26 x 1.95" Kenda Comfort w/ K-shield

Controls and contact points

Archived: Headset: 1 1/8" Threaded · Handlebar: Custom LBC Riser · Stem: Alloy Adjustable · Seatpost: Alloy Suspension, 27.2mm diameter · Saddle: Avenir Comfort · Pedals: Avenir Comfort Platform
