Velopedia Bicycle Archive

2010 Diamondback Drifter 3

Original specifications: Cruiser Mix drivetrain · 26" wheels.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #21624
Model year
2010
Category
Cruiser
Sizes
Men's 18"
Colors
Matte Gold
In this record
23 specifications
Model history 1 other year

Browse other years

Compare side by side

Identification clues

2010 archived details

Published colors
Matte Gold
Frame
6061-T6 heat treated OS aluminum
Original equipment
Cruiser Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original build6061-T6 heat treated OS aluminum · Cruiser Mix · 26" wheels

Historical catalog variants

Archived sizes and colors

1 item record

Item-level catalog entries recovered from Velopedia’s original bicycle archive. They document how this model was listed historically; they do not identify the frame size associated with legacy reference geometry or indicate current availability.

Published sizes

Men's 18"

Published colors

Matte Gold
View 1 archived size/color combination
SizeColor
Men's 18"Matte Gold

Historical catalog evidence. Exact specifications and naming may vary by market, production run or manufacturer revision.

Frameset

Frame ConstructionTIG-welded
Frame Material6061-T6 heat treated OS aluminum
ForkDB Custom Cruiser
Fork MaterialSingle

Drivetrain

Component GroupCruiser Mix
ShiftersShimano Nexus
Crankset1-piece, 44 teeth
Bottom BracketLoose ball
CassetteCog
Rear Cogs3-speed internal, 20 teeth
PedalsCruiser Platform

Brakes

BrakesCoaster brake rear

Cockpit & Contact Points

Headset1 1/8" Threaded
HandlebarDiamondback Cruiser
Handlebar ExtensionsNot included
StemAlloy Cruiser Hi-Rise Quill
SaddleDrifter Double Spring
SeatpostAlloy Pillar, 27.2mm diameter

Wheels & Tires

HubsFront: Nutted, Rear: Shimano Nexus 3 speed Internal Gear
RimsAmuz Alloy, 36-hole
SpokesStainless, 14ga. (2.0mm)
Front Tire26 x 2.125" Kenda Cruiser whitewall
Wheel Size26" wheels

Gearing

Original gearing is incomplete. Enter your setup to calculate ratios and cadence speeds.

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Seatpost · Original
Alloy Pillar

27.2mm diameter

Search Amazon Search eBay
Retailer offers
Front tire · Original
26 x 2.125" Kenda Cruiser whitewall
Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
26 x 2.125" Kenda Cruiser whitewall
Drivetrain
3-speed
Seatpost diameter
27.2 mm
Bottom bracket / shell
Loose ball
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded · Fork: DB Custom Cruiser · Single

Drivetrain

Check drivetrain wear →

Archived: Group: Cruiser Mix · Shifters: Shimano Nexus · Crankset: 1-piece, 44 teeth · Bottom bracket: Loose ball · Cassette: Cog · Rear cogs: 3-speed internal, 20 teeth

Brakes

Inspect the brakes →

Archived: Brakes: Coaster brake rear

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 26" wheels · Rims: Amuz Alloy, 36-hole · Hubs: Front: Nutted, Rear: Shimano Nexus 3 speed Internal Gear · Front tire: 26 x 2.125" Kenda Cruiser whitewall

Controls and contact points

Archived: Headset: 1 1/8" Threaded · Handlebar: Diamondback Cruiser · Stem: Alloy Cruiser Hi-Rise Quill · Seatpost: Alloy Pillar, 27.2mm diameter · Saddle: Drifter Double Spring · Pedals: Cruiser Platform
