Velopedia Bicycle Archive
2009 Diamondback Scapegoat
Mountain bike, front & rear suspension bicycle from the Velopedia historical specification archive.
- Original MSRP
- $0.00
- Sizes
- Small, medium, large
- Colors
- Black Sheep
- Archive ID
- 18908
Image not yet recovered
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Aluminum w/hydroformed TT & butted DT |
| Fork | Fox 36 Float RC2, 160mm travel |
| Fork Material | Aluminum/magnesium, single crown |
| Rear Shock | Fox DHX Air 5.0, 6" travel |
Drivetrain
| Component Group | SRAM Hammerschmidt |
|---|---|
| Shifters | SRAM X.0 Trigger |
| Front Derailleur | Internally Geared Crank |
| Rear Derailleur | SRAM X.0 short cage |
| Crankset | TruVativ Hammerschmidt |
| Bottom Bracket | TruVativ Hammerschmidt |
| Cassette | SRAM PG-990 |
| Rear Cogs | 9-speed, 11 - 34 teeth |
| Chain | SRAM PC-991 |
| Pedals | DB Sound alloy |
Brakes
| Brakes | Avid Code w/203mm rotor front/Avid Code w/185mm rotor rear brakes, Avid Code levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/2" FSA Orbit E |
|---|---|
| Handlebar | Answer Products Pro Taper OS riser |
| Handlebar Extensions | Not included |
| Stem | TruVativ Holzfeller |
| Saddle | WTB Laser V Race |
| Seatpost | TruVativ Team Dual Bolt, 30.9mm diameter |
Wheels & Tires
| Hubs | Front: Mavic CrossMax SX 20mm Thru-axle, Rear: Mavic Crossmax SX |
|---|---|
| Rims | Mavic CrossMax SX UST, 24-hole |
| Spokes | Mavic Zicral, bladed |
| Front Tire | Front: 26 x 2.50" WTB Prowler MX, Rear: 26 x 2.30" WTB Stout |
| Wheel Size | 26" wheels |
Historical specifications are presented as an archival reference. Component specifications may have varied by market, size, or production run.
