2009 Diamondback Clarity 2
Road/sport bicycle from the Velopedia historical specification archive.
- Original MSRP
- $0.00
- Sizes
- Womens xsmall, womens small, womens medium
- Colors
- Quartz Gray Metallic
- Archive ID
- 18947
Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061-T6 butted aluminum |
| Fork | Insight integrated aero |
| Fork Material | Alloy, single crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | Shimano Alivio |
|---|---|
| Shifters | Shimano Alivio Rapid Fire |
| Front Derailleur | Shimano Alivio |
| Rear Derailleur | Shimano Alivio |
| Crankset | Shimano FC-M411, 28/38/48 teeth |
| Bottom Bracket | Sealed cartridge |
| Cassette | SRAM PG-820 |
| Rear Cogs | 8-speed, 11 - 32 teeth |
| Pedals | DB Platform |
Brakes
| Brakes | Avid SD-3 brakes, Avid FR-5 levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" Integrated Cane Creek style |
|---|---|
| Handlebar | DB low rise alloy |
| Handlebar Extensions | Not included |
| Stem | DB 3D Forged 31.8 |
| Saddle | DB Devine Performance Hybrid w/Gel |
| Seatpost | Alloy Micro Adjust, 27.2mm diameter |
Wheels & Tires
| Hubs | Alloy |
|---|---|
| Rims | Freedom RCX 2.0, 20-hole/24-hole |
| Spokes | Stainless, 14ga. (2.0mm) |
| Front Tire | 700 x 32c Kenda Kwick Trax w/K-shield |
| Wheel Size | 700c wheels |
Historical specifications are presented as an archival reference. Component specifications may have varied by market, size, or production run.
