2004 Diamondback Nitrus
BMX bicycle from the Velopedia specification archive.
- Original MSRP
- $198.00
- Sizes
- Expert
- Colors
- Charcoal Grey
- Archive ID
- 31724
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | 6061 T6 aluminum |
| Fork Material | Hi-tensile steel, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | 1-piece 175mm, 44 teeth |
| Bottom Bracket | Loose ball, splined |
| BB Shell Width | American |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z410, 1/2 x 1/8" |
| Pedals | Aluminum |
Brakes
| Brakes | Tektro rear brakes, Tektro 317 rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless FSA |
|---|---|
| Handlebar | DB Expert |
| Handlebar Extensions | N/A |
| Stem | Aluminum |
| Saddle | Padded |
| Seatpost | Aluminum, 26.8mm diameter |
Wheels & Tires
| Hubs | Aluminum |
|---|---|
| Rims | Alex C303, 36-hole |
| Spokes | UCP |
| Spoke Nipples | Brass nipples |
| Front Tire | Front: 20 x 2.125" Comp III style, Rear: 20 x 1.75" Comp III style |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
