2001 Diamondback Sherman
Freestyle/jumping bicycle from the Velopedia specification archive.
- Original MSRP
- $499.99
- Sizes
- Pro
- Colors
- Tainted White
- Archive ID
- 36063
Current market
Checking current listings…Frameset
| Frame Construction | TIG-welded |
|---|---|
| Frame Material | Chromoly |
| Fork | Diamondback |
| Fork Material | Chromoly, unicrown crown |
| Rear Shock | N/A |
Drivetrain
| Component Group | N/A |
|---|---|
| Shifters | N/A |
| Front Derailleur | N/A |
| Rear Derailleur | N/A |
| Crankset | 3-piece chromoly 180mm, 44 teeth |
| Bottom Bracket | Sealed |
| Rear Cogs | 1-speed, 16 teeth |
| Chain | KMC Z410, 1/2 x 1/8" |
| Pedals | Aluminum platform |
Brakes
| Brakes | Tektro FX-10 rear brakes, Tektro 373A rear levers |
|---|
Cockpit & Contact Points
| Headset | 1 1/8" threadless Tange-Seiki TGMX |
|---|---|
| Handlebar | Chromoly jump |
| Handlebar Extensions | Not included |
| Stem | Aluminum |
| Saddle | DB Urban Camo padded |
| Seatpost | Steel micro-adjust, 25.4mm diameter |
Wheels & Tires
| Hubs | RMX aluminum sealed bearing |
|---|---|
| Rims | Alex MX 22, 48-hole |
| Front Tire | 20 x 2.125" Diamondback Crazy Train |
| Wheel Size | 20" wheels |
Specifications are presented as a reference. Components may vary by market, size, production run, or later manufacturer revisions.
