1996 Diamondback Outlook 24

Original specifications: Shimano Tourney TY-22 drivetrain · 24" wheels · 29.8 lb published weight.

Share owner experience

Planning to sell? Draft your listing

No archive photo is available for this record.

At a glance

Archive #54703
Model year
1996
Category
Kids
Original MSRP
$215.00
Sizes
Boys 11", boys 13", girls 11", girls 13"
Colors
Black, Night Storm, Wild Berry
Weight
29.8 lb
Geometry
Legacy reference
In this record
25 specifications · original MSRP · geometry
Model history 4 other years

Browse other years

Compare side by side

Identification clues

1996 archived details

Published colors
Black, Night Storm, Wild Berry
Frame
Hi-tensile steel
Original equipment
Shimano Tourney TY-22

Clues, not proof of model year. Colors vary and components may have been replaced.

Campaign
Original buildHi-tensile steel · Shimano Tourney TY-22 · 24" wheels

Manufacturer catalog

Published sizes and colors

4 sizes · 3 colors

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

Boys 11"boys 13"girls 11"girls 13"

Published colors

BlackNight StormWild Berry

Frameset

Frame ConstructionTIG-welded steel
Frame MaterialHi-tensile steel
ForkDiamondback
Fork MaterialHi-tensile steel

Drivetrain

Component GroupShimano Tourney TY-22
ShiftersShimano Tourney TY-22 top-mount
Front DerailleurShimano Tourney TY-15, bottom-pull
Rear DerailleurShimano Tourney TY-22
CranksetSugino Grande 50, 28/38/48 teeth
Bottom BracketVictor VPB-33
BB Shell Width68mm English
Rear Cogs6-speed, 14 - 28 teeth
ChainKMC UG-50, 1/2 x 3/32"
PedalsVictor VP-882

Brakes

BrakesLee Chi 713A brakes, Lee Chi 398AP-1 levers

Cockpit & Contact Points

Headset1" Victor VP-H67
HandlebarHsin Lung MTB 110
StemHsin Lung MTS 31300-1
SaddleDiamondback Jr MTB
SeatpostSteel, 25.8 mm diameter

Wheels & Tires

RimsFL-219 alloy, 36-hole
SpokesSteel, 2.0mm straight gauge
Spoke NipplesBrass nipples
Front Tire24 x 1.95" Cheng Shin
Wheel Size24" wheels

Geometry

Legacy reference · 5 measurements

Historical measurements. Frame size unknown.

All geometry measurementsLegacy reference · 5 measurements
MeasurementLegacy reference
Top tube460 mm
Head-tube angle70°
Seat-tube angle70°
Chainstay / rear center415 mm
Fork offset / rake50 mm

Frame size not recorded.

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build48/38/28T · 14–28T · 6-speed
Lowest1.00:1 Highest3.43:1 Total range343%
Estimated speed At 90 RPM Lowest gear6.4 mph Highest gear21.9 mph

Uses front tire 24×1.95; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications
Front tire · Original
24 x 1.95" Cheng Shin Replacement search: 24x1.95 bicycle tire Before ordering: Check rim type and tire clearance.
Search Amazon Search eBay
Front derailleur · Original
Shimano Tourney TY-15

bottom-pull

Search eBay
Rear derailleur · Original
Shimano Tourney TY-22
Search eBay
More parts (2)Fewer parts
Shifters · Original
Shimano Tourney TY-22 top-mount
Search eBay
Seatpost · Original
Steel

25.8 mm diameter

Search Amazon Search eBay

Based on the original build. Check fit and installed parts before ordering. Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
24 x 1.95" Cheng Shin
Drivetrain
6-speed
Seatpost diameter
25.8 mm
Bottom bracket / shell
Victor VPB-33 · 68mm English
Campaign
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Frame and fork

Inspect the frame and fork →

Archived: Frame: TIG-welded steel · Fork: Diamondback · Hi-tensile steel

Drivetrain

Check drivetrain wear →

Archived: Group: Shimano Tourney TY-22 · Shifters: Shimano Tourney TY-22 top-mount · Front derailleur: Shimano Tourney TY-15, bottom-pull · Rear derailleur: Shimano Tourney TY-22 · Crankset: Sugino Grande 50, 28/38/48 teeth · Bottom bracket: Victor VPB-33 · Rear cogs: 6-speed, 14 - 28 teeth · Chain: KMC UG-50, 1/2 x 3/32"

Brakes

Inspect the brakes →

Archived: Brakes: Lee Chi 713A brakes, Lee Chi 398AP-1 levers

Wheels and tires

Check wheels and tires →

Archived: Wheel size: 24" wheels · Rims: FL-219 alloy, 36-hole · Front tire: 24 x 1.95" Cheng Shin

Controls and contact points

Archived: Headset: 1" Victor VP-H67 · Handlebar: Hsin Lung MTB 110 · Stem: Hsin Lung MTS 31300-1 · Seatpost: Steel, 25.8 mm diameter · Saddle: Diamondback Jr MTB · Pedals: Victor VP-882
