Velopedia Bicycle Archive

2004 Devinci Milano

Original specifications: Shimano Alivio · 8-speed · mechanical rear derailleur · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #92044
Model year
2004
Category
City & Commuter
Sizes
L, M, S, womens medium, womens small, XS
In this record
26 specifications · archived image
Model history 4 other years

Browse other years

Compare side by side

Identification clues

2004 archived details

Frame
Aluminum
Original equipment
Hybrid Mix

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum · Hybrid Mix · 700c wheels

Manufacturer catalog

Published sizes and colors

6 sizes

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

LMSwomens mediumwomens smallXS

Frameset

Frame ConstructionTIG-welded
Frame MaterialAluminum
ForkSR Suntour CR880
Fork MaterialAluminum, single crown

Drivetrain

Component GroupHybrid Mix
ShiftersShimano Acera EF35
Front DerailleurShimano Nexave T401
Rear DerailleurShimano Alivio
CranksetTruVativ Five-D, 30/42/52 teeth
Bottom BracketTruVativ cartridge, 118.5mm spindle
BB Shell Width68mm English
Rear Cogs8-speed, 11 - 30 teeth
ChainShimano CN-IG31, 1/2 x 3/32"
PedalsWellgo aluminum

Brakes

BrakesProMax SX-V85 linear-pull brakes, Shimano EF-35 levers

Cockpit & Contact Points

Headset1 1/8" threadless Tien Hsin TH-23 Integrated
HandlebarKalloy aluminum riser
StemKalloy aluminum
SaddleSelle Italia XO TransAm
SeatpostSuspension

Wheels & Tires

HubsShimano HB-RM40
RimsAlex DA-16, 32-hole
SpokesDT stainless steel, 14ga. (2.0mm) straight gauge
Spoke NipplesBrass nipples
Front Tire700 x 35c Michelin Transworld
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

Published build52/42/30T · 11–30T · 8-speed
Lowest1.00:1 Highest4.73:1 Total range473%
Estimated speed At 90 RPM Lowest gear7.3 mph Highest gear34.5 mph

Uses front tire 700C×35; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Chain · Original
Shimano CN-IG31

1/2 x 3/32"

Front tire · Original
700 x 35c Michelin Transworld
Brake pads · Original
ProMax SX-V85 linear-pull brakes

Shimano EF-35 levers

More parts (5)Fewer parts
Saddle · Original
Selle Italia XO TransAm
Rear derailleur · Original
Shimano Alivio
Shifters · Original
Shimano Acera EF35
Rims · Original
Alex DA-16

32-hole

Hubs · Original
Shimano HB-RM40

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 35c Michelin Transworld
Drivetrain
8-speed
Bottom bracket / shell
TruVativ cartridge, 118.5mm spindle · 68mm English
Equipment inspection checks 11 checks based on 6 archived component groups Open equipment checksClose equipment checks
0 of 11 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: SR Suntour CR880 · Aluminum, single crown

Archived: Fork: SR Suntour CR880

Archived: Group: Hybrid Mix · Shifters: Shimano Acera EF35 · Front derailleur: Shimano Nexave T401 · Rear derailleur: Shimano Alivio · Crankset: TruVativ Five-D, 30/42/52 teeth · Bottom bracket: TruVativ cartridge, 118.5mm spindle · Rear cogs: 8-speed, 11 - 30 teeth · Chain: Shimano CN-IG31, 1/2 x 3/32"

Archived: Brakes: ProMax SX-V85 linear-pull brakes, Shimano EF-35 levers

Archived: Wheel size: 700c wheels · Rims: Alex DA-16, 32-hole · Hubs: Shimano HB-RM40 · Front tire: 700 x 35c Michelin Transworld

Controls and contact points

Archived: Headset: 1 1/8" threadless Tien Hsin TH-23 Integrated · Handlebar: Kalloy aluminum riser · Stem: Kalloy aluminum · Seatpost: Suspension · Saddle: Selle Italia XO TransAm · Pedals: Wellgo aluminum
