2004 Devinci Apogee

Original specifications: Campagnolo Centaur drivetrain · 700c wheels.

Share owner experience

Planning to sell? Draft your listing

At a glance

Archive #92026
Model year
2004
Category
Road
Sizes
XS, S, M, L
In this record
26 specifications · archived image
Model history 2 other years

Browse other years

Compare side by side

Identification clues

2004 archived details

Frame
Aluminum/carbon fiber
Original equipment
Campagnolo Centaur

Clues, not proof of model year. Colors vary and components may have been replaced.

Original buildAluminum/carbon fiber · Campagnolo Centaur · 700c wheels

Manufacturer catalog

Published sizes and colors

4 sizes

Manufacturer-published sizes and colors; availability and exact size/color pairings may vary by market or production run.

Published sizes

XSSML

Frameset

Frame ConstructionTIG-welded
Frame MaterialAluminum/carbon fiber
ForkColumbus Carve
Fork MaterialCarbon fiber w/carbon fiber steerer, aero crown

Drivetrain

Component GroupCampagnolo Centaur
ShiftersCampagnolo Centaur Ergo
Front DerailleurCampagnolo Centaur, bottom-pull/braze-on
Rear DerailleurCampagnolo Centaur
CranksetFSA Carbon Pro, 39/53 teeth
Bottom BracketFSA Platinum ISIS, 109.5mm spindle
BB Shell Width68mm English
Rear Cogs10-speed, 11 - 23 teeth
ChainCampagnolo Record, 1/2 x 3/32"
PedalsNot included

Brakes

BrakesCampagnolo Centaur dual pivot brakes, Campagnolo Centaur Ergo levers

Cockpit & Contact Points

Headset1 1/8" threadless Tien Hsin TH-16 Integrated
Handlebar3T Forgie XL
Stem3T Forgie XL
SaddleSelle Italia SLR
SeatpostCarbon fiber

Wheels & Tires

HubsMavic Ksyrium Elite
RimsMavic Ksyrium Elite
SpokesMavic stainless steel, straight gauge
Spoke NipplesAluminum nipples
Front Tire700 x 23c Michelin Axial Pro Race
Wheel Size700c wheels

Gearing

Lower gears help on climbs. Higher gears suit higher speeds.

RPM

RPM = pedal turns per minute.

All published sizes53/39T · 11–23T · 10-speed
Lowest1.70:1 Highest4.82:1 Total range284%
Estimated speed At 90 RPM Lowest gear11.9 mph Highest gear33.9 mph

Uses front tire 700C×23; rear size isn’t listed.

How it works

Ratio = front teeth ÷ rear teeth. Hub gears also include the hub’s internal ratio. A 400% range means the highest ratio is four times the lowest.

Speeds are estimates from tire size and pedal cadence. Actual speeds vary.

Try other gearing

Try your current gearingChanged tires or gears? Calculate your setup.

Your changes apply to this calculation. The archived build stays unchanged.

Your gearing setup
Gears

Use up to three front tooth counts, separated by /. For one rear sprocket, enter the same count twice.

Rear tire

Apply the marking on your rear tire or edit its dimensions below. Older or fractional inch sizes need the ISO marking (e.g. 37-590).

For 32-622, width is 32 mm and rim diameter is 622 mm. Use the rear tire on mixed-wheel bikes. Leave both fields empty to compare ratios only.

Gear, dimension and cadence changes update results automatically.

Speeds are estimates. These calculations do not establish component compatibility or available tire clearance.

Parts & serviceability

Find replacement parts

Original specifications

Affiliate links may earn Velopedia a commission. As an Amazon Associate I earn from qualifying purchases.

Front tire · Original
700 x 23c Michelin Axial Pro Race
Bottom bracket · Original
FSA Platinum ISIS

109.5mm spindle

Saddle · Original
Selle Italia SLR
More parts (5)Fewer parts
Crankset · Original
FSA Carbon Pro

39/53 teeth

Rear derailleur · Original
Campagnolo Centaur
Shifters · Original
Campagnolo Centaur Ergo
Rims · Original
Mavic Ksyrium Elite
Hubs · Original
Mavic Ksyrium Elite

Based on the original build. Check fit and installed parts before ordering.

Parts and service referenceQuick reference before buying parts

Archived specifications for reference. Check the fitted parts before ordering.

Front tire
700 x 23c Michelin Axial Pro Race
Drivetrain
10-speed
Bottom bracket / shell
FSA Platinum ISIS, 109.5mm spindle · 68mm English
Equipment inspection checks 10 checks based on 5 archived component groups Open equipment checksClose equipment checks
0 of 10 checked Progress stays in this browser for this record.

Checks selected from the archived equipment. Confirm what is fitted today. This is not a complete safety inspection; use the full inspection guide before test riding.

Full used-bike inspection guide →

Archived: Frame: TIG-welded · Fork: Columbus Carve · Carbon fiber w/carbon fiber steerer, aero crown

Archived: Group: Campagnolo Centaur · Shifters: Campagnolo Centaur Ergo · Front derailleur: Campagnolo Centaur, bottom-pull/braze-on · Rear derailleur: Campagnolo Centaur · Crankset: FSA Carbon Pro, 39/53 teeth · Bottom bracket: FSA Platinum ISIS, 109.5mm spindle · Rear cogs: 10-speed, 11 - 23 teeth · Chain: Campagnolo Record, 1/2 x 3/32"

Archived: Brakes: Campagnolo Centaur dual pivot brakes, Campagnolo Centaur Ergo levers

Archived: Wheel size: 700c wheels · Rims: Mavic Ksyrium Elite · Hubs: Mavic Ksyrium Elite · Front tire: 700 x 23c Michelin Axial Pro Race

Controls and contact points

Archived: Headset: 1 1/8" threadless Tien Hsin TH-16 Integrated · Handlebar: 3T Forgie XL · Stem: 3T Forgie XL · Seatpost: Carbon fiber · Saddle: Selle Italia SLR · Pedals: Not included
