Velopedia Bicycle Archive

1997 Dean Castanza (03)

Road race & triathlon bicycle from the Velopedia specification archive.

Original MSRP
$2,335.00
Sizes
50 cm, 52 cm, 54 cm, 56 cm, 58 cm, 60 cm, custom
Colors
Satin
Weight
20
Archive ID
64372
Image not yet recovered

Current market

Checking current listings…

Frameset

Frame ConstructionTIG-welded
Frame Material3Al/2.5V titanium
ForkKestrel EMS
Fork MaterialCarbon fiber composite, aero crown
Rear ShockN/A

Drivetrain

Component GroupShimano 600 Ultegra
ShiftersShimano 600 Ultegra STI Dual Control
Front DerailleurShimano 600 Ultegra, top-pull/clamp-on 31.8 mm
Rear DerailleurShimano 600 Ultegra
CranksetShimano 600 Ultegra, 39/53 teeth
Bottom BracketShimano BB-UN72, 115 mm spindle
BB Shell Width68mm English
Rear Cogs8-speed, 12 - 23 teeth
ChainShimano CN-HG91, 1/2 x 3/32"
PedalsNot included

Brakes

BrakesShimano 600 Ultegra Dual Pivot brakes, Shimano 600 Ultegra levers

Cockpit & Contact Points

Headset1" Shimano 600 Ultegra
HandlebarTTT Forma SL
Handlebar ExtensionsN/A
StemDean aluminum
SaddleSelle San Marco Concor Lite
SeatpostDean aluminum, 27.2 mm diameter

Wheels & Tires

HubsShimano 600 Ultegra
RimsMavic Reflex SUP, 32-hole
SpokesWheelsmith stainless steel, 2.0mm double butted
Spoke NipplesBrass nipples
Front Tire700 x 23c Michelin Super Comp HD
Wheel Size700c wheels
